GV-PBL8800 Geovision 1.68mm 25fps @ 8MP Outdoor IR Day/Night WDR Panoramic Bullet IP Security Camera 12VDC/PoE

Specifications

Camera

• Image Sensor - 1/2.8" progressive scan CMOS
• Picture Elements - 3840 (H) x 2160 (V)
• Minimum Illumination - Color: 0.012 Lux (F2.0, AGC ON)
• Shutter Speed - Auto / Manual (1 ~ 1/100000 sec)
• White Balance - Automatic, Manual
• Gain Control - Automatic, Manual
• S/N Ratio - 55 dB
• WDR Pro - Yes
• Dynamic Range - 120 dB

Lens

• Megapixel - 8 MP
• Day/Night -Yes (with removable IR-cut filter)
• Lens Type - Fixed
• Focal Length - 1.68mm
• Maximum Aperature - F/2.0
• Mount - M12
• Horizontal FOV - 180°
• Operation
  • Focus - Fixed
  • Zoom - Fixed
  • Iris - Fixed
• IR LED Quantity - 2 IR LEDs
• Max. IR Distance - 15 m (50 ft)

Operation

• Video Compression - H.265, H.264, MJPEG
• Video Streaming - Triple streams
• Video Resolution
  • Main Stream - 3840 x 2160(Default), 3456 x 1936, 3200 x 1800, 2880 x 1624, 2560 x 1440, 1920 x 1080, 1280 x 720
  • Sub Stream - 704 x 576, 640 x 480(Default), 640 x 360, 352 x 288, 320 x 240, 320 x 192
  • Third Stream (Closed by Default) - 1280 x 720, 704 x 576, 640 x 480(Default), 640 x 360, 352 x 288, 320 x 240, 320 x 192
• Frame Rate
  • 60Hz: 25fps@3840x2160, 30fps@3456x1936, 30fps@3200x1800, 30fps@2880x1624, 30fps@2560x1440, 30fps@1920x1080, 30fps@1280x720
  • 50Hz: 25fps@3840x2160, 25fps@3456x1936, 25fps@3200x1800, 25fps@2880x1624, 25fps@2560x1440, 25fps@1920x1080, 25fps@1280x720, 30fps@704x576, 30fps@640x480, 30fps@640x360, 30fps@352x288, 30fps@320x240, 30fps@320x192 (60Hz/50Hz)
  • * The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)
• Video Analytics - Motion Detection, Audio Alarm, Tamper Detection. *Tampering detection and audio alarm are only accessible through the camera's Web interface, which can be used to trigger alerts such as e‐mail and FTP
• Heat Map - On / Off
• Image Setting - Brightness, Contrast, Saturation, Sharpness, Flicker-less, 3D Noise Reduction, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270°‐including Corridor format)
• Audio Compression - G.711 / G.722 / G.726
• Audio Support - One‐way Audio (built-in microphone)

Network

• Interface - 10/100 Ethernet
• Protocol - IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, ONVIF Profile (G, Q, S, T)

Deep Learning Function

• AI Perimeter Protection - Line Crossing, Region Entrance, Region Exiting, Advanced Motion Detection, Loitering (Human & Vehicle classification), Object Left, Object Removed, People Counting

Mechanical

• Camera Angle Adjustment
  • Pan - 0 ~ 360°
  • Tilt - 5° ~ 90°
  • Rotate - 0 ~ 360°
• Connectors
  • Power - DC JACK (DC 12 V, 1.25 A), PoE
  • Ethernet - RJ‐45
  • Audio - 1 In (built‐in microphone with power supply)
  • Local Storage - Micro SD card slot (SD / SDHC / SDXC / UHS-I, Class 10). * UHS-II card type is not supported

General

• Operating Temperature - -40°C ~ 60°C (-40°F ~ 140°F)
• Humidity - 0 ~ 90% (no condensation)
• Power Source - 12V DC / PoE (IEEE 802.3af)
• Max. Power Consumption - 9 W
• Dimensions - 95.8 x 74 x 158.5 mm (3.77 x 2.91 x 6.24")
• Weight - 0.63 kg (1.39 lb)
• Ingress Protection - IP67
• Vandal Resistance - IK10 for metal casing
• Regulatory - CE, FCC compliant

Web Interface

• Installation Management - Web‐based configuration
• Maintenance - Firmware upgrade through Web Browser or Utility
• Access from Web Browser - Live View, Video Recording, Change Video Quality, Bandwidth Control, Image Snapshot, Text Overlay, Image Masking
• Language - English, Korean, Traditional Chinese, Turkish, German, Polish, Italian, Japanese, French, Persian, Portuguese, Russian, Czech, Dutch, Thai, Bulgarian, Arabic, Slovenian, Finnish, Spanish

GV-PBL8800 Specifications PDF
