GV-RFER12700 Geovision 1.6mm 15FPS @ 12MP Outdoor IR Day/Night WDR Fisheye IP Security Camera 12VDC/PoE

GV-RFER12700 is a 12 MP outdoor fisheye camera allowing you to monitor all angles of a location and can be installed to the ceiling or the wall. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality image at reduced network bandwidths. The camera adheres to IP66 standard and can be powered through PoE.

Specifications

Camera

• Image Sensor - 1/3" progressive scan CMOS
• Picture Elements - 3840 (H) x 3000 (V)
• Minimum Illumination
  • Color - 0.01 Lux (F1.6, AGC ON)
  • IR On - 0 Lux
• Shutter Speed - Auto / Manual (1/3 ~ 1/100000 sec)
• White Balance - Auto, Manual
• Gain Control - Auto, Manual
• S/N Ratio - 39.5 dB
• WDR - Yes

Lens

• Megapixel - Yes
• Day / Night - Yes (with removeable IR-cut filter)
• Lens Type - Fixed
• Focal Length - 1.6mm
• Maximum Aperture - F/2
• Mount - M12
• Image Format - 1/2.3"
• Horizontal FOV - 180°
• Operation
  • Focus - Fixed
  • Zoom - Fixed
  • Iris - Fixed
• IR LED Quantity - 3 IR LEDs
• Max. IR Distance - 10 m (35 ft)

DORI

• Lens - 1.6mm
• Detect - 41.3 m (135.4 ft)
• Observe - 16.5 m (54.1 ft)
• Recognize - 8.3 m (27.2 ft)
• Identify - 4.1 m (13.4 ft)

Operation

• Video Compression - H.265, H.264
• Video Streaming - Triple streams from H.265, & H.264
• Frame Rate
  • 25 fps at 3000 x 3000, 2560 x 2560, 2160 x 2160, 1520 x 1520, 480 x 480 (50/ 60 Hz) 15 fps at 3840 x 3000, 1280 x 960, 640 x 480 (50 / 60 Hz)
  • *The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes)
• Video Analytics - Motion Detection, Audio Alarm, *Tamper detection and audio alarm are only accessible through the camera's Web interface, which can be used to trigger alerts such as e‐mail and FTP
• Image Setting - Brightness, Contrast, Saturation, Sharpness, IR-CUT Mode, IR CUT Delay, IR-LED Low Beam Light, Angle Trad, White Balance, Shutter, Time Exposure, 3D Noise Reduction, WDR, White Balance, Display Mode, Image Orientation (Flip, Mirror, 90°, 180° - including Corridor format)
• Software Dewarping
  • Ceiling Mount - Fisheye View, Cylinder, 2 PTZ, 4 PTZ, 180° panorama image, 360° panorama image, 360° panorama image and PTZ, 360° panoramic image and 3 PTZ, 360° panoramic image and 6 PTZ, 360° panoramic image and 8PTZ, Fisheye and 3 PTZ, Fisheye and 8 PTZ
  • Wall - Fisheye View, Panorama, 4 PTZ, 360° panoramic image and 3 PTZ, 360° panoramic image and 8 PTZ, Fisheye and 3 PTZ, Fisheye and 8 PTZ
  • Desktop - Fisheye View, Cylinder, 4 PTZ, 180° panorama image, 360° panorama image, 360° panorama image and PTZ, 360° panoramic image and 3 PTZ, 360° panoramic image and 6 PTZ, 360° panoramic image and 8 PTZ
  • Tilt - Fisheye View, Panorama, 4 PTZ, 360° panoramic image and 3 PTZ, 360° panoramic image and 8 PTZ, Fisheye and 3 PTZ, Fisheye and 8 PTZ
• Audio Compression - G.711
• Audio Support - Two‐way Audio
• Digital I/O
  • Input - 1 Input, dry contact, NO / NC
  • Output - 1 Relay Output (2A 30V DC / 0.5A 125V AC)

Video Resolution

• Video Resolution
  • Main Stream - 3840 x 3000, 3000 x 3000 (Default), 2560 x 2560, 2160 x 2160, 1520 x 1520
  • Sub Stream - 1280 x 960 (Default), 640 x 480, 480 x 480
  • Third Stream (Closed by Default) - 640 x 480, 480 x 480

Network

• Interface - 10/100 Ethernet
• Protocol - 802.1x, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, IPv4, IPv6, NTP, ONVIF (Profile G, S, T), RTP/RTSP, SMTP, SNMP, TCP, UPnP

Mechanical

• Connectors
  • Power - DC Jack
  • Ethernet - RJ-45
  • Audio - 1 In (built-in microphone), 1 Out (built-in speaker)
  • Digital I/O -4-pin terminal block pitch 3.5 mm (0.14")
  • Local Storage - Micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10), up to 256 GB *UHS-II card type is not supported

General

• Operation Temperature - -35°C~ 60°C (-31°F ~ 140°F)
• Humidity - 0% ~ 95% (no condensation)
• Power Source - 12VDC/ PoE (IEEE802.3af)
• Max. Power Consumption - 9.6W
• Dimensions - Ø 120 x 55 mm (4.7" x 2.1")
• Weight - 400 g (0.88 lb)
• Ingress Protection - IP66
• Certification - CE, FCC, RoHS compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or GV-IP Device Utility
• Language - English, German, Spanish, French, Japanese, Italian, Portuguese, Russian, Turkish, Traditional Chinese, Korean, Ukrainian

Applications

• Software Supported - GV‐VMS (V17.4.7 / V18.3.2, patch files required), GV‐Control Center (V4.3, coming soon), GV‐Recording Server / Video Gateway (V2.2, coming soon), GV‐Edge Recording Manager Win version (V2.3, coming soon
• Smart Device Access - GV-Eye for iOS and Android (V3.2.0 coming soon)
• Live Viewing - Browser (IE, Edge, Chrome, Firefox, Safari), Mobile App
