GV-GBLN4800-2F Geovision 2.8 mm 30FPS @ 4MP AI-ISP Warm LED Outdoor Day/Night WDR Bullet IP Security Camera 12VDC/PoE

The Bullet IP Camera is an outdoor, network camera equipped with AI-ISP and smart warm LEDs for full color surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. GV-GBLN4800 adheres to IP67 and IK10 standards, and can be powered through PoE.

Specifications

Camera

• Image Sensor - 1/1.79" progressive scan CMOS
• Picture Elements - 2688 (H) x 1520 (V)
• Minimum Illumination
  • Color - 0.0001 Lux (F1.0, AGC ON)
  • LED On - 0 Lux
• Shutter Speed - Automatic / Manual (1/3 ~ 1/100000 sec)
• White Balance - Automatic, Manual
• Gain Control - Automatic, Manual
• S/N Ratio - 50 dB
• WDR Pro - Yes
• Dynamic Range - 120 dB

Lens

• Megapixel - 4MP
• Day / Night - Color
• Lens Type - Fixed
• Focal Length - 2.8 mm
• Maximum Aperture - F/1.0
• Mount - M12
• FOV
  • Horizontal - 112°
  • Vertical - 61°
  • Diagonal - 132°
• Operation
  • Focus - Auto / Manual
  • Zoom - Fixed
  • Iris - Fixed
• Warm LED Quantity - 3 Warm LEDs
• Max. Warm LED Distance - 30 m (100 ft)

DORI

• Lens - 2.8 mm
• Detect - 52 m (170.6 ft)
• Observe - 21 m (68.8 ft)
• Recognize - 10 m (32.8 ft)
• Identify - 5 m (16.4 ft)

Operation

• Video Compression - H.265, H.265+, H.264, H.264+, MJPEG
• Video Streaming - Triple streams from H.265, H.264 or MJPEG
• Frame Rate
  • 30 fps at 2688 x 1520, 2560 x 1440, 1920 x 1080, 1280 x 720, 704 x 480, 640 x 480, 640 x 360, 480 x 240, 352 x 240 (60 Hz)
  • 25 fps at 2688 x 1520, 2560 x 1440, 1920 x 1080, 1280 x 720, 704 x 567, 640 x 480, 640 x 360, 480 x 240, 352 x 288 (50 Hz)
  • *The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)
• Maximum Throughput - 8 Mbps
• Maximum Streams *When the total bitrate is within the maximum throughput - 10
• Video Analytics - Motion Detection, Video Exception Detection (Abnormal Color Detection, Scene Change, Video Blur), Object Abandoned/Missing Detection
• Smart Alarm - Audio Exception, Cable Disconnection, IP Address Conflict, SD Card Error, SD Card Full
• Image Setting - Brightness, Contrast, Hue, Saturation, Sharpness, Defog, Antiflicker, 3D Noise Reduction, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270°‐including Corridor format)
• Audio Compression - G.711
• Audio Support - One-way Audio

Video Resolution

• Main Stream - 2688 x 1520 (Default), 2560 x 1440, 1920 x 1080
• Sub Stream - 1280 x 720 (Default), 704 x 480, 704 x 567, 640 x 480, 640 x 360, 480 x 240, 352 x 240, 352 x 288
• Third Stream - 1280 x 720 (Default), 704 x 480, 704 x 567, 640 x 480, 640 x 360, 480 x 240, 352 x 240, 352 x 288

Network

• Interface - 10/100 Ethernet
• Protocol - 802.1x, API, DDNS, DHCP, FTP, HTTP, HTTP POST, HTTPS, IPv4, IPv6, NTP, ONVIF (Profile G, S, T), PPPoE, QoS, RTCP, RTMP, RTP, RTSP, SMTP, SNMP, UDP, UPnP

Deep Learning Function

• AI Perimeter Protection
  • Face Event - Face Detection
  • Smart Event - - Line Crossing, Region Entrance, Region Exiting, Region Intrusion, Target Counting
  • *Face Event and Smart Event can only be enabled one at a time

Mechanical

• Camera Angle Adjustment
  • Pan - 0° ~ 360°
  • Tilt - 0° ~ 90°
  • Rotate - 0° ~ 360°
• Connectors
  • Power - DC jack
  • Ethernet - RJ-45
  • Audio
    • Built-in microphone - Yes
    • External microphone required - Yes (audio jack, 3.5 mm )
    • Built-in speaker - No
    • External speaker required - No
    • * For devices with microphone or speaker, choose either the built-in or external option.
    • * If equipped with an Audio In port, it only supports microphones with power supply.
  • Digital I/O - N/A
  • Local Storage - microSD card slot (SD / SDHC / SDXC), up to 512 GB

General

• Operation Temperature - -30~ 60°C (-22 ~ 140°F)
• Humidity - 0% ~ 95% (no condensation)
• Power Source - DC 12V, 1.5A / PoE (IEEE 802.3af)
• Max. Power Consumption - 6.5W
• Dimensions - 218.1 x 70.4 x 79.5 mm (8.58 x 2.77 x 3.12 in)
• Weight - 0.71 kg (1.57 lb)
• Ingress Protection - IP67
• Vandal Resistance - IK10 for metal casing
• Certification - CE, FCC, RoHS compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or GV-IP Device Utility
• Access from Web Browser - Live View, Playback, Video Recording, Image Quality, Bandwidth Control, Image Snapshot, One‐way Audio, Digital Zoom, Text Overlay, Image Masking, Intelligent Mark
• Language - Czech, Dutch, English, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Spanish (LA), Traditional Chinese, Turkish, Ukrainian

Applications

• Software Supported - GV-VMS (V17.4.8 / V18.3.5 or later, patch files required), GV-Control Center (V4.2.1 or later, patch files required), GV-Edge Recording Manager for Windows (V2.3.0 or later, patch files required), GV-Recording Server (V2.1.1 or later, patch files required)
• Smart Device Access - GV-Eye for iOS (V3.4.1 or later), GV Eye for Android (V3.4.1 or later)
• Live Viewing - Web Browser (Chrome, Edge, Firefox, Safari), Mobile App

GV-GBLN4800-2F Specifications PDF
