GV-GDR4900+1TB Geovision 2.8mm 30FPS @ 4MP Outdoor IR Day/Night WDR Mini Fixed Rugged IP Dome Security Camera 12VDC/PoE + 1TB Micro SD

GV-GDR4900 is an outdoor camera designed with IK10 vandal resistance and IP67 ingress protection. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. The camera adheres to IK10 and IP67 standards, and can be powered through PoE.

Specifications

Camera

• Image Sensor - 1/3" progressive scan CMOS
• Picture Elements - 2688 (H) x 1520 (V)
• Minimum Illumination
  • Color - 0.005 Lux (F1.6, AGC ON)
  • IR On - 0 Lux
• Shutter Speed - Automatic / Manual (1/3 ~ 1/100000 sec)
• White Balance - Automatic, Manual
• Gain Control - Automatic, Manual
• S/N Ratio - 50 dB
• WDR Pro - Yes
• Dynamic Range - 120 dB

Lens

• Megapixel - 4MP
• Day / Night - Yes (with removeable IR-cut filter)
• Lens Type - Fixed
• Focal Length - 2.8
• Maximum Aperture - F/1.6
• Mount - M12
• FOV
  • Horizontal - 95.3°
  • Vertical - 53.2°
  • Diagonal - 100.7°
• Operation
  • Focus - Fixed
  • Zoom - Fixed
  • Iris - Fixed
• IR LED Quantity - 2 IR LEDs
• Max. IR Distance - 20 m (65 ft)

DORI

• Lens - 2.8mm
• Detect - 60.6 m (198.8 ft)
• Observe - 24.2 m (79.3 ft)
• Recognize - 12.1 m (39.6 ft)
• Identify - 6.0 m (19.6 ft)

Operation

• Video Compression - H.265, H.265+, H.264, H.264+, MJPEG
• Video Streaming - Triple streams
• Video Resolution
  • Main Stream - 2688 x 1520 (Default), 2592 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080
  • Sub Stream - 1280 x 720 (Default), 704 x 576, 704 x 480, 640 x 480, 640 x 360, 480 x 240, 352 × 240
  • Third Stream - 1280 x 720 (Default), 704 x 576, 704 x 480, 480 x 240, 352 x 240
• Frame Rate
  • 30 fps at 2688 x 1520 / 2592 x 1520 / 2560 x 1440 / 2304 x 1296 / 1920 x 1080 / 1280 x 720 / 704 x 480 / 640 x 480 / 640 x 360 / 480 x 240 / 352 x 240 (60 Hz)
  • 25 fps at 2688 x 1520 / 2592 x 1520 / 2560 x 1440 / 2304 x 1296 / 1920 x 1080 / 1280 x 720 / 704 x 576 / 640 x 480 / 640 x 360 / 480 x 240 / 352 x 288 (50 Hz)
  • *The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)
• Maximum Throughput
  • AI off - 64 Mbps
  • AI on - 18 Mbps: one AI function enabled, 12 Mbps: multiple AI functions enabled
• Maximum Streams *When the total bitrate is within the maximum throughput - 8 *By default, 2 connections are occupied whether connected to GV-Cloud VMS or not
• Video Analytics - Motion Detection, Video Exception Detection (Abnormal Color Detection, Scene Change, Video Blur), Object Abandoned/Missing Detection
• Smart Alarm - Audio Exception, Cable Disconnection, IP Address Conflict, SD Card Error, SD Card Full
• Image Setting - Brightness, Contrast, Saturation, Sharpness, Flicker-less, 3D Noise Reduction, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270°‐including Corridor format)
• Dual Redundant Images - Yes (for failsafe firmware upgrade)
• Audio Compression - G.711
• Audio Support - Two-way audio (external speaker required)
• Digital I/O
  • Input - 1 Input, dry contact, NO / NC
  • Output - 1 Relay Output (1A 30V DC / 0.3A 125V AC)

Deep Learning Function

• AI Analytics
  • Face Event - Face Detection
  • Smart Event - - Line Crossing, Region Entrance, Region Exiting, Region Intrusion, Target Counting, Heat Map, Video Metadata: Human & Vehicle classification, - Loitering Detection, Illegal Parking Detection
  • *A maximum of 2 smart detection functions are suggested at a time to ensure comprehensive detection results and the optimized performance by the camera
  • *Once connected to GV-Cloud VMS / GV-Center V2, up to 2 smart detection functions are supported
• Video Metadata
  • People - Gender, Age, Top / Bottom (Type, Color), Accessories (Hat, Bag, Face Mask, Glasses)
  • Vehicle - Type, Color, Brand, Model
  • Non-Motor Vehicle - Type

Network

• Interface - 10/100 Ethernet
• Protocol - 802.1x, DDNS, DHCP, FTP, HTTP POST, HTTP, HTTPs, IPv4, IPv6, NTP, ONVIF (Profile G, S, T, M), PPPoE, QoS, RTCP, RTMP, RTP, RTSP, SMTP, SNMP, UDP, UPnP

Mechanical

• Camera Angle Adjustment
  • Pan - 0° ~ 360°
  • Tilt - 0° ~ 75°
  • Rotate - 0° ~ 350°
• Connectors
  • Power - DC Jack (DC 12 V, 1 A) / PoE (IEEE 802.3af)
  • Ethernet - RJ-45
  • Audio
    • Built-in microphone - Yes
    • External microphone required - Yes (audio jack, 3.5 mm or 0.14 in)
    • Built-in speaker - No
    • External speaker required - Yes (audio jack, 3.5 mm or 0.14 in)
    • * Choose either the built-in or external option for devices with a microphone or speaker
    • The Audio In port only supports microphones with a power supply.
  • Digital I/O - 4‐pin terminal block pitch 3.5 mm (0.14”)
  • Local Storage - microSD card slot (SD / SDHC / SDXC), up to 256 GB

General

• Operation Temperature - -30~ 60°C (-22 ~ 140°F)
• Humidity - 0% ~ 95% (no condensation)
• Power Source - DC 12V, PoE (IEEE802.3af)
• Max. Power Consumption - 5.5W
• Dimensions - Ø 110.4 x 62 mm (Ø 4.3 x 2.4")
• Weight - 0.42 kg (0.93 lb)
• Ingress Protection - IP67
• Vandal Resistance - IK10 for metal casing
• Certification - CE, FCC, RoHS compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or Utility
• Access from Web Browser - Live View, Playback, Video Recording, Image Quality, Bandwidth Control, Image Snapshot, Two‐way Audio Capable, Digital Zoom, Text Overlay, Image Masking, Intelligent Mark
• Language - Chinese Traditional, Czech, Dutch, English, French, German, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Spanish(Latin America), Turkish

Software Applications

• Software Supported - GV-VMS (V17.4.6 / V18.3.2 or later), GV-Edge Recording Manager (V2.2.5 or later), GV-Control Center (V4.1.0 or later), GV-Recording Server (V2.3.0, coming soon), GV-Center V2 (V18.4.1 or later), GV-Cloud VMS (V1.3.0 or later
• Smart Device Access - GV-Eye for iOS and Android (V3.1.1 or later)
• Live Viewing - Web Browser (Edge, IE mode in Edge, Chrome, Firefox, Safari), Mobile APP

GV-GDR4900+1TB Specifications PDF
