GV-GDRF4800-3F Geovision 3.6mm 30FPS @ 4MP Super Low Lux Outdoor IR Day/Night WDR Fixed Mini Dome IP Security Camera 12VDC/PoE

GV‐GDRF4800 is a 4 MP outdoor mini fixed rugged IP dome camera, equipped with smart white LEDs for full color surveillance during nighttime. The camera supports H.265 video codec to achieve a better compression ratio while maintaining high-quality pictures at reduced network bandwidth. GV‐GDRF4800 adheres to IP67 and IK10 standards and can be powered through PoE.

Specifications

Camera

• Image Sensor - 1/3" progressive scan CMOS
• Picture Elements - 2560 (H) x 1440 (V)
• Minimum Illumination
  • Color - 0.005 Lux (F1.6, AGC ON)
  • IR On - 0 Lux
• Shutter Speed - Automatic / Manual (1/3 ~ 1/100000 sec)
• White Balance - Automatic, Manual
• Gain Control - Automatic, Manual
• S/N Ratio - 50 dB
• WDR Pro - Yes
• Dynamic Range - 120 dB

Lens

• Megapixel - 4MP
• Day / Night - Yes (with removeable IR-cut filter)
• Lens Type - Fixed
• Focal Length - 3.6 mm
• Maximum Aperture - F/1.6
• Mount - M12
• Image Format - 1/3”
• FOV
  • Horizontal - 78°
  • Vertical - 40°
  • Diagonal - 97°
• Operation
  • Focus - Fixed
  • Zoom - Fixed
  • Iris - Fixed
• IR LED
  • Quantity - 2 IR LED
  • Max. IR Distance - 30 m (100 ft)
• Smart Illumination
  • Quantity - 2 White LEDs
  • Max. White LED Light Distance - 30 m (100 ft)

DORI

• Lens - 3.6mm
• Detect - 79 m (259.1 ft)
• Observe - 32 m (104.9 ft)
• Recognize - 16 m (52.4 ft)
• Identify - 8 m (26.2 ft)

Operation

• Video Compression - H.265, H.265+, H.264, H.264+, MJPEG
• Video Streaming - Triple streams
• Video Resolution
  • Main Stream - 2560 x 1440 (default), 2304 x 1296, 1920 x 1080, 1280 x 720
  • Sub Stream - 1280 x 720 (default), 704 x 480, 704 x 576, 640 x 480, 352 x 240, 352 x 288
  • Third Stream - 704 x 480 (default), 704 x 576, 480 x 240, 352 x 240, 352 x 288
• Frame Rate
  • Max. 30 fps (60 Hz) at 2560 x 1440, 2304 x 1296, 1920 x 1080, 1280 x 720, 704 x 480, 640 x 480, 480 x 240, 352 x 240
  • Max. 25 fps (50 Hz) at 2560 x 1440, 2304 x 1296, 1920 x 1080, 1280 x 720, 704 x 576, 640 x 480, 480 x 240, 352 x 288
  • *The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)
• Maximum Throughput - 6 Mbps
• Maximum Streams *When the total bitrate is within the maximum throughput - 6
• Smart Alarm - Motion Detection, SD Card Error, SD Card Full, IP Address Conflict, Cable Disconnection, Scene Change Detection, Video Blur Detection, Abnormal Color Detection
• Video Analytics - Motion Detection, Object Abandoned / Missing Detection, Video Exception
• Image Setting - Brightness, Contrast, Hue, Saturation, Sharpness, 3D Noise Reduction, BLC, Antiflicker, White Balance, Shutter, Gain, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270° - including Corridor format)
• Audio Compression - G.711
• Audio Support - One-way Audio

Deep Learning Function

• AI Analytics - Line Crossing, Region Intrusion (Human & Vehicle classification) *The two functions can only be enabled one at a time.

Network

• Interface - 10/100 Ethernet
• Protocol - 802.1x, DDNS, DHCP, FTP, HTTP POST, HTTP, HTTPS, IPv4, IPv6, NTP, ONVIF (Profile G, S, T, M), PPPoE, QoS, RTCP, RTMP, RTP, RTSP, SMTP, SNMP, UDP, UPnP

Mechanical

• Camera Angle Adjustment
  • Pan - 0° ~ 355°
  • Tilt - 0° ~ 70°
  • Rotate - 0° ~ 180°
• Connectors
  • Power - DC jack
  • Ethernet - RJ-45
  • Audio
    • Built-in microphone - Yes
    • External microphone required - Yes (audio jack, 3.5 mm )
    • Built-in speaker - No
    • External speaker required - No
    • * Choose either the built-in or external microphone.
    • * The Audio In port only supports microphones with a power supply.
  • Local Storage - microSD card slot (SD / SDHC / SDXC), up to 256 GB

General

• Operation Temperature - -30~ 60°C (-22 ~ 140°F)
• Humidity - 0% ~ 95% (no condensation)
• Power Source - DC 12V, 1A / PoE (IEEE 802.3af)
• Max. Power Consumption - 5.5W
• Dimensions - Ø 119 × 87.8 mm (Ø 4.7 × 3.5 in)
• Weight - 0.64 kg (1.41 lb)
• Ingress Protection - IP67
• Vandal Resistance - IK10 for metal casing
• Certification - CE, FCC, RoHS, UKCA compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or Utility
• Access from Web Browser - Live View, Playback, Video Recording, Image Quality, Bandwidth Control, Image Snapshot, Digital Zoom, Text Overlay, Image Masking, Intelligent Mark
• Language - Chinese Traditional, Czech, Dutch, English, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Spanish (Latin America), Turkish, Ukrainian

Software Applications

• Software Supported - GV-VMS (V17.4.8 / V18.3.5 or later, patch files required), GV-Control Center (V4.2.1.0 or later), GV-Edge Recording Manager (V2.3.0 or later), GV-Recording Server (V2.1.1 or later, patch files required), GV-IP Device Utility (V9.0.4 or later)
• Smart Device Access - GV-Eye for iOS and Android (V3.4.1 or later)
• Live Viewing - Web Browser (Chrome, Edge, Firefox, Safari), Mobile App

GV-GDRF4800-3F Specifications PDF
