GV-TMS8800 2-in-1 25FPS @ 4MP Outdoor IR Day/Night WDR Dome IP Security Camera 12VDC/PoE

GV-TMS8800 features two 4MP CMOS image sensors to deliver a video resolution of 2688 x 1520 at up to 25 fps. It’s an outdoor, fixed, network camera equipped with an automatic IR-cut filter and two IR LEDs for day and night surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. The camera adheres to IP67 and IK10 standards, and can be powered through PoE.

Specifications

Camera

• Image Sensor - 1/3" progressive scan CMOS
• Picture Elements - 2688 (H) x 1520 (V)
• Minimum Illumination
  • Color - 0.002 Lux (F1.6, AGC ON)
  • IR ON - 0 Lux
• Shutter Speed - Auto / Manual (1 ~ 1/100000 sec)
• White Balance - Automatic, Manual
• Gain Control - Automatic, Manual
• S/N Ratio - Up to 52 dB
• WDR Pro - Yes
• Dynamic Range - 130 dB

Lens

• Megapixel - 4 MP for each lens
• Day / Night - Yes (with removable IR-cut filter)
• Lens Type - Fixed
• Focal Length - 2.8 mm
• Maximum Aperture - F/1.6
• Mount - Ø 12 mm
• Horizontal FOV - 97.7°
• Operation
  • Focus - Fixed
  • Zoom - Fixed
  • Iris - Fixed
• IR LED Quantity - 2 IR LEDs
• Max. IR Distance - 30 m (100 ft)

DORI

• Lens - 2.8 mm
• Detect - 63.0 m (206.7 ft)
• Observe - 25.2 m (82.7 ft)
• Recognize - 12.6 m (41.3 ft)
• Identify - 6.3 m (20.7 ft)

Operation

• Video Compression - H.265, H.264, MJPEG
• Video Streaming - Triple streams from H.265, H.264 or MJPEG
• Frame Rate - 25 fps at 2688 x 1520, 2560 x 1440, 30 fps at 2304 x 1296, 1920 x 1080, 1280 x 720 (60 / 50 Hz). *The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)
• Maximum throughput - 50 Mbps
• Maximum stream *When the total bitrate is within the maximum throughput - 20
• Video Analytics - Motion Detection, Ultra Motion Detection, Tampering Alarm, Audio Detection *Tampering alarm and audio detection are only accessible through the camera’s Web interface, which can be used to trigger alerts such as e-mail and FTP
• Image Setting - Brightness, Saturation, Contrast, Sharpness, Flicker-less, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270° ?including Corridor format)
• Audio Compression - G.711
• Audio Support - Two?way Audio (external speaker required)
• Digital I/O
  • Input - 1 Input, dry contact, NO/NC
  • Output - 1 Relay Output (DC 30V, 1A / AC 125V, 0.3A)

Face Detection

• Environment - 100 lux
• Detectable face angle
  • Tilt (Up/Down) - ? 10°
  • Swing (Left/Right) - ? 30°
• Max. number of faces - Up to 40
• Min. face image pixel requirement - 80 pixels

Deep Learning Function

• AI Analytics
  • Sensor 1 - Intrusion, Cross Line, Entering Area, Face Detection, Leaving Area, People Flow Counting, Crowd Density Monitoring
  • Sensor 2 - Intrusion, Cross Line, Entering Area, Leaving Area

Network

• Interface - 10/100 Ethernet
• Protocol - 802.1x, ARP, DHCP, DDNS, DNS, DynDNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, TCP, UDP, UPnP, ONVIF (Profile G, S, T)

Video Resolution

• Main Stream - 2688 x 1520 (Default), 2560 x 1440, 2304 x 1296, 1920 x 1080, 1280 x 720
• Sub Stream - 1280 x 720, 720 x 576, 704 x 288, 640 x 480, 640 x 360 (Default), 352 x 288
• Third Stream (Closed by Default) - 720 x 576, 704 x 288, 640 x 360, 352 x 288

Mechanical

Camera Angle Adjustment

• Pan - 0° ~ 180°
• Tilt - 0° ~ 66°
• Rotate - 0° ~ 346°

Connectors

• Power - DC Jack (DC 12V, 1.25A), PoE (IEEE 802.3af)
• Ethernet - RJ-45
• Audio
  • Built-in microphone - Yes
  • External microphone required - Yes (3-pin terminal block)
  • Built-in speaker - No
  • External speaker required - Yes (3-pin terminal block)
  • *Choose either the built-in or external microphone
  • *The audio in port only supports microphones with power supply
• Digital I/O - 4-pin terminal block pitch 3.5 mm (0.14”)
• Local Storage - Micro SD card slot (SD / SDHC / SDXC / UHS-I, Class 10) *UHS-II card type is not supported

General

• Operating Temperature - -30°C ~ 60°C (-22°F ~ 140°F)
• Humidity - 0% ~ 95% (no condensation)
• Power Source - DC 12V, 1.25A / PoE (IEEE802.3af)
• Max. Power Consumption - 9.1 W
• Dimensions - 176 × 104 × 72 mm (6.9” × 4.1’’ × 2.8”)
• Weight - 0.62 kg (1.37 lb)
• Ingress Protection - IP67
• Vandal Resistant - IK10 for metal casing
• Certification - FCC, CE, RoHS, UL compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or GV-IP Device Utility
• Access from Web Browser - Live View, Video Recording, Change Video Quality, Bandwidth Control, Image Snapshot, Defog, Text Overlay, Image Masking
• Language - Czech, English, French, German, Hungarian, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Traditional Chinese

Software Applications

• Software Supported (by patch) - GV-VMS (V17.4.8 / V18.3.5, coming soon, patch files required), GV-Control Center (V4.2.1.0, patch files required), GV-Edge Recording Manager Windows Version (V2.2.8, patch files required), GV-Recording Server / Video Gateway (V2.1.1, patch files required) *GV-TMS8800 occupies two channels of GV-VMS
• Smart Device Access - GV-Eye for iOS / Android (V3.4.0, coming soon)
• Live Viewing - Browser (IE, Edge, Chrome, Firefox), Mobile APP
