DWG

TL-R1200PES-RP-US QNAP 12-Bay 2U Rackmount PCIe Interface SATA JBOD Expansion Enclosure

SKU: TL-R1200PES-RP-US
Brand: QNAP
  • Expand up to 2.0 PB capacity for QuTS hero NAS, by connecting twelve expansion enclosures (up to 144 hard drives in total)
  • Just connect your TL-R1200PES-RP to the host NAS to expand NAS capacity. RAID re-building on the host NAS is not required, and setup is finished within a few minutes
  • The TL-R1200PES-RP supports SATA hard drives, which are common, budget-friendly, and available with large capacities
  • The TL-R1200PES-RP power on/off is linked with the host NAS
  • The TL-R1200PES-RP features PCIe Gen 3 x8, providing up to 64 Gb/s data transfer speed
  • Ensures service continuity with stable and reliable power supplies
More details...
MPN: TL-R1200PES-RP-US
UPC: 885022025589
MSRP Price: $1,499.00
Online Price: $1,499.00
Save to my Wish List

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.



Product Details

The TL-R1200PES-RP TL PCIe interface SATA JBOD storage enclosure allows you to expand the storage capacity of a QuTS hero or QTS NAS by using SATA hard drives. Providing large data capacity and fast transfer speed, the TL-R1200PES-RP is the ideal solution for archiving/backing up virtualization applications, surveillance recordings, large data, and multimedia.

Specifications

  • Drive Bay
    • 12 x 3.5-inch SATA 6Gb/s
    • The system is shipped without HDD
  • Drive Compatibility
    • 3.5-inch bays
    • 3.5-inch SATA hard disk drives
    • 2.5-inch SATA solid state drives
  • Hot-swappable - Yes
  • Form Factor - 2U Short Depth Rackmount
  • Host Interface - 2 x SFF-8644 1x2 (in, out)
  • LED Indicators - Front panel: HDD 1-12, Power, Status, Link, Fan error, Rear panel: SAS connector, Enclosure ID
  • Buttons - Power
  • Dimensions (HxWxD) - 3.49 x 18.98 x 16.69 inch
  • Weight (Net) - 20.33 lbs
  • Weight (Gross) - 30.91 lbs
  • Max. number of HDDs/SSDs supported - 12
  • Hard Drive Type - 3.5" or 2.5" SATA 6Gb/s and 3Gb/s drives
  • Operating Temperature - 0 - 40 °C (32°F - 104°F)
  • Storage Temperature - -20 - 70°C (-4°F - 158°F)
  • Relative Humidity - 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
  • Power Supply Unit - 300W (x2), 100 - 240V
  • Fan - 2 x 80mm, 12VDC
  • System Warning - Buzzer
  • Management Managed
    • via QNAP QTS / QuTS hero OS
    • 1. Supports disk S.M.A.R.T. information
    • 2. RAID expansion enclosure identifier
    • 3. Locate RAID expansion enclosures
    • 4. Locate hard disks on RAID expansion enclosure
    • 5. Smart fan control by detecting system and hard drive temperature
    • 6. Support Host-Based Power Management

TL-R1200PES-RP-US Specifications PDF

Check out some additional items that you may need to purchase with this product:
Check the check boxes next to the additional products that you would like to add to the shopping cart, then click on the "Add to Cart" button above. A check box is not shown if a product requires that you select an option or fill out a field. () indicates a required accessory.
