HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone

HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone

HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone

HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone	HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone	HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone
(Click to see larger image and other views)

HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone

HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone

HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone	HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone	HNW-SS-806 Hanwha Vision Line Level Wall Mounted Microphone
(Click to see larger image and other views)

Search available promotions and discounts for this Item

SKU: HNW-SS-806

Brand: Hanwha Vision

Line level wall mounted microphone

Features:

Line level wall mounted microphone.
Anti-ligature and vandal-resistant design.
12 gauge stainless steel.
Omni-Directional pickup with 12â€™ radius/24â€™ diameter
12Vdc power required @20mA
30Hz-15kHz
2.2kÎ© Output Impedance, 60dB SNR. 4.75â€H x 2.5â€W

More details...

Search available promotions and discounts for this Item

MPN: HNW-SS-806
EAN: 849688022290

Save to my Wish List

Already a DWG Dealer? - Sign In to view pricing.

Product Details

Specifications

Sensitivity - -38db Â± 2
Frequency Response - 30Hz - 15kHz
Power Requirements - 12Vdc
Current Drain - 20mA
Output Impedance - 2.2KÎ©
SNR - 60 dB
Operating Temp - -25Â° - 70Â° C
Weight - 12oz
Faceplate Dimensions - 4.75"H x 2.5"W
Faceplate Thickness - 11 Gauge
Faceplate Material - Stainless Steel

HNW-SS-806 Specifications PDF
