SLA-T2480V Hanwha Techwin 2.4mm 1080p Lens

Specifications

Video

• Imaging Device - 1/2.8" 2M CMOS
• Total Pixels - 1,945(H) x 1,109(V) 2.16M
• Effective Pixels - 1,945(H) x 1,097(V) 2.13M
• Scanning System - Progressive Scan
• Min. Illumination
  • Color : 0.45 Lux (F2.0)
  • B/W : 0.45 Lux (F2.0)
• S / N Ratio - 50dB
• Wide Dynamic Range - 120dB
• Day & Night - Electrical

Lens

• Focal Length (Zoom Ratio) - 2.4mm
• Max. Aperture Ratio - F2.0
• Angular Field of View - H : 138° / V : 73° / D : 168°
• Min. Object Distance - 0.3m (0.98ft)
• Lens Type - Fixed focal
• Mount Type - RJ12 connected with main unit

Environmental

• Operating Temperature /Humidity - 10°C ~ +55°C (+14°F ~ +131°F) /Less than 90% RH
• Storage Temperature /Humidity - 50°C ~ +60°C (-58°F ~ +140°F) /Less than 90% RH

Mechanical

• Color / Material
  • Lens : Black / Plastic, Metal
  • Cable : Black
• Dimensions (WxHxD)
  • Lens : 30 x 27.9 x 45mm (1.18" x 0.10" x 1.77")
  • Cable : 8m (314.96")
• Weight - 328g (0.72 lb)

SLA-T2480V Specifications PDF
