SPD-152 Hanwha Vision 64 Channel Network Video Decoder

SPD-152 Hanwha Vision 64 Channel Network Video Decoder	SPD-152 Hanwha Vision 64 Channel Network Video Decoder	SPD-152 Hanwha Vision 64 Channel Network Video Decoder
(Click to see larger image and other views)

SPD-152 Hanwha Vision 64 Channel Network Video Decoder	SPD-152 Hanwha Vision 64 Channel Network Video Decoder	SPD-152 Hanwha Vision 64 Channel Network Video Decoder
(Click to see larger image and other views)

There are currently no active sales or promotions related to this item.

SKU: SPD-152

Clone & Expand mode support (HDMI#1 UHD, HDMI#2 FHD)
Maximum 64 channels (HDMI 1 Clone mode), 36 (HDMI 1) / 25 (HDMI 2) Expand mode
Maximum decoding performance 8MP@60fps, 2MP@360fps
ONVIF, SUNAPI, RTSP cameras supported
Freely adjust camera size to highlight important areas (Tile merge)
H.265, H.264, MJPEG codec support
Up to 20 layouts and sequence
Fisheye dewarping, PTZ Controls, thermal camera temperature check, save snapshot to USB drive
Management using USB mouse or web interface
Easy installation with included VESA monitor-back mount or pole mount with optional pole straps
PoE and DC 12V Dual power for Power Redundancy Failover
NDAA / FCC Compliant
TAA compliant model: SPD-152/KEX

Video & audio decoding up to 64 cameras on dual HDMI outputs. Designed for easy monitoring stations without the cost or complexity of a workstation

There are currently no active sales or promotions related to this item.

MPN: SPD-152
EAN: 8801089218957

Add to List

Already a DWG Dealer? - Sign In to view pricing.

Product Details

System

Video Output

HDMI#1 - 1EA (up-to 4K), Audio support
HDMI#2 - 1EA (up-to 1080p), Audio not support
Video-out Format - 3840 X 2160@30Hz (HDMI#1) 2560 X 1440@30Hz (HDMI#1) 1920 X 1080@60Hz (HDMI#1, HDMI#2) 1280 X 1024@60Hz (HDMI#1, HDMI#2) 1280 X 720@60Hz (HDMI#1, HDMI#2)

External

Network

Environmental

Electrical

Mechanical

Software

Video

Codec - H.265 / H.264 / MJPEG
Max. Decoding Performance - 8M@60fps, 2M@360fps
Division (/Monitor) - Clone mode (HDMI#1) Max. 64 Expand mode (HDMI#1) Max. 36 (HDMI#2) Max. 25
Layout - Up to 20, Sequence support

Video

Codec - G.711 / G.726 / AAC
Management - Local UI, Web-Viewer
Time Setting - NTP/Manual
Export/Import - Configuration Export/Import
Log - Max. 100,000 (System log)
Protocol - RTP, RTSP, HTTP, CGI (SUNAPI), ONVIF
Security - IP address filtering, User access Log, 802.1x, Encryption, Device certificate(Hanwha Techwin Root CA), Signed firmware
