Nuvico DV3 Series 8 Channel MPEG4 Digital Video Recorder-DISCONTINUED

Specifications:

• Model Number - NVDV3-8000N
• Video Signal - Support NTSC & PAL Standards
• Operating System - Embedded Linux
• Triplex Function - Simultaneous - Record / Playback / Network / Backup
• Video Input - 8
• Video Output - 1 Main Monitor, 1 S-Video, 1 Spot Out, 1 VGA
• Loop Out - 8
• Live Display - 1, 4, 6, 8
• Playback Displays - 1, 4, 6, 8
• Video Compression Method - MPEG-4
• Average File SIze - 2.5 ~ 8 KB
• Live Display Resolution - 720 x 480(NTSC), 720 X 576(PAL)
• Live Display Rate - 240pps(NTSC), 200(PAL)
• Recording Rate & Resolution - 120pps @ 360 X 240, 60pps @ 720 X 240, 30pps @ 720 X 480.
• Alarm In / Out - 8 / 1
• System Control - Key Buttons, IR Remote Controller, Remote Client PC
• Audio In/Out - 4 / 1
• PTZ Dome & Controller Interface - RS-422 / 485
• Display Settings - Brightness, Contrast, Color Adjustments, Hidden/Covert Per Channel
• Camera Title - 8 Characters Per Channel
• Recording Modes - Continuous, Schedule, Alarm, Motion, Overwrite
• Recording Adjustments - 8 Levels of Resolution / Recording Frame Rate Adjustment per Channel
• Pre-Alarm & Post Alarm Recording - Pre-Alarm: 140pps / Post-Alarm: 20 sec. ~ 240 sec.
• Motion Detection Per Channel - 16 Selectable Grids / 15 Sensitivity Levels
• Search Modes - Time & Date, Camera, Alarm, Motion
• Playback Modes - Forward & Reverse: Pause, Field by Field, Normal Speed, 2X, 4X, 8X, 16X
• Power Failure Recovery - Auto Reboot while Maintaining Previous Record Settings
• Alarm Notification - Automatic E-mail : External Alarm, Video Loss, Power Loss, HDD Failure
• System Utility - 2-Level Password / Auto Lock / Disk Format / Disk Check / Fan Lock Detection
• Internal Backup Device - CD-RW or DVD-RW
• External Backup Device - USB2.0: Memory Stick & External HDD
• Mini-Player for Backup - Installing dedicated software into PC is not required to playback files from CD or DVD
• Communication Port - USB2.0, RS-232C, RS-422/485, Ethernet
• Storage Capacity - Upto 1.2TB: 3 Internal HDD Bays
• Network - LAN, WAN, Internet, PSTN Line
• External Telephone Modem Support - RS-232C
• Remote Client Software - Multi-site / Enterprise Level Client Software or Web Browser(IE 6.0)
• Dynamic IP Support over Cable - Dedicated Host ID per unit. DVR will automatically self reconfigure everytime IP address changes.
• IR Remote Controller - Control Upto 99 DVRs
• Power - 100 ~ 230VAC, Selectable
• Dimensions - 360(W) x 340(D) x 100(H)
• Weight - 6 Kg
• Operating Temperature - 0°C ~ 40°C

NVDV3-8000N Spec Sheet
