SP-6820-GR-0 Awid Sentinel-Prox Reader - Gray

Search available promotions and discounts for this Item

SKU: SP-6820-GR-0

Brand: Awid

AWID's SP-6820 Proximity Card Reader is a switchplate-type reader that combines exceptional reading distance and easy mounting directly on a single-gang box. With a read range up to 8 inches, the SP-6820 reader delivers excellent performance without compromising quality, durability, attractive appearance, and ease of installation.

More details...

Search available promotions and discounts for this Item

MPN: SP-6820-GR-0

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Convenient size - Fits like a cover plate on a box or wall
Clean, handsome design - Matches good architecture at site
Ready for heavy use at all sites - Non-contact reading of cards and tags
Perfect for wall, cabinet, single-gang box - Strong two-part ABS plastic enclosure
Easy mounting - 2 screws match holes in a utility box
Special read range in a small unit - Up to 8 inches with cards
Visual and audible indicators - 3-color LED and beeper inside reader
Controllable functions in reader - LED, beeper, hold can be wired to panel
Easy power - Connects to panel's DC terminals
Quick wiring to host panel - Basic 4-wire hook-up; 7 wires maximum
Standard Wiegand data output - Data-0 & Data-1 panel connections
Alternative RS-232 data output - Interface to PC or special controller
Uniform code formats - Standard 26-bit plus special codes
No programming in reader - SP-6820 is ready to read all AWID codes
Self-testing for good operation - LED & beeper indicate performance
High value ratio - Excellent performance; low cost
