XNP-6120H Hanwha Techwin 5.2 - 62.4mm 12x Optical Zoom 60FPS @ 1920 x 1080 Outdoor Day/Night WDR PTZ IP Security Camera 12VDC/POE

WiseNet X powered by WiseNet 5 network outdoor PTZ camera, 2MP, Full HD(1080p) @ 60fps WDR off/on(120dB) or @30fps WDR on(150dB), 12X optical zoom lens (5.2mm ~62.4mm) (54.58° ~ 5.30°), Pan: 360° Endless. Tilt: -5°~ 185°, H.265/H.264/MJPEG, WiseStream II compression technology, 150dB WDR, USB port for easy installation, Advanced video analytics and sound classification, True D/N, Dual SD card, HLC, Defog detection, DIS , 12VDC/PoE, IP66, IK10, -22°F ~ 131°F

Specifications

Video

• Imaging Device- 1/2.8" 2.16M CMOS
• Total Pixels- 1,945(H) x 1,109(V), 2.16M
• Effective Pixels- 1,945(H) x 1,097(V), 2.13M
• Scanning System- Progressive
• Min. Illumination- Color : 0.03 Lux (F1.6, 1/30sec), B/W : 0.003 Lux (F1.6, 1/30sec)
• S / N Ratio- 50dB
• Video Out- CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for Installation USB : Micro USB Type B, 1280 x 720 for Installation

Lens

• Focal Length (Zoom Ratio)- 5.2 ~ 62.4mm (Optical 12X)
• Max. Aperture Ratio- F1.6 (Wide) ~ F3.0(Tele)
• Angular Field of View- H : 54.58˚(Wide) ~ 5.30˚(Tele) / V : 32.19˚(Wide) ~ 3.00˚(Tele)
• Min. Object Distance- 1.5m (4.92ft)(Wide), 2.1m (6.89ft) (Tele)
• Focus Control- Auto / Manual / One shot AF
• Lens / Mount Type- DC Auto Iris / Board-in Type

Pan /Tilt /Rotat e

• Pan / Tilt Range- 360˚ Endless / 190˚(-5˚ ~ 185˚)
• Pan Speed- Preset : 350˚/sec, Manual : 0.024˚/sec ~ 200˚/sec
• Tilt Speed- Preset : 350˚/sec, Manual : 0.024˚/sec ~ 200˚/sec
• Sequence / Preset Accuracy- Preset (300 ea), Swing, Group (6 ea), Trace, Tour (1 ea), Auto Run, Schedule / ±0.2˚
• Azimuth- Yes (E / W / S / N / NE / NW / SE / SW)
• Auto Tracking- Support

Operat ional

• Camera Title- Off / On (Displayed up to 85 Characters) W/W : English / Numeric / Special Characters China : English / Numeric / Special / Chinese Characters Common : Multi-line (Max. 5), Color (Grey / Green / Red / Blue / Black / White), Transparency, Auto scale by Resolution
• Day & Night- Auto (ICR) / Color / B/W / Schedule
• Backlight Compensation- Off / BLC / HLC / WDR
• Wide Dynamic Range- 150dB
• Contrast Enhancement- SSDR (Off / On)
• Digital Noise Reduction- SSNRV (2D + 3D Noise filter) (Off / On)
• Digital Image Stabilization- Off / On (Built-in Gyro)
• Defog- Auto / Manual / Off
• Motion Detection- Off / On(8ea, Polygonal)
• Privacy Masking- Off / On ( 24 Zones of Rectangle zone) - Color : Grey / Green / Red / Blue / Black / White - Zoom ratio option for mask mode - Mosaic option
• Gain Control- Off / Low / Middle / High
• White Balance- ATW / AWC / Manual / Indoor / Outdoor (included Mercury & Sodium)
• Electronic Shutter Speed- Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec)
• Digital Zoom- 32x
• Flip / Mirror- Off / On
• Video & Audio Analytics- Tampering, Loitering, Directional Detection,Fog Detection, Virtual Line, Enter/Exit, Dis) Appear, Audio Detection, Face Detection, Motion Detection Sound Classification
• Serial Interface- RS-485 - Samsung-T/E, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell
• Alarm I/O- Input 1ea / Output 1ea (Relay type)
• Alarm Triggers- Alarm Input, Motion Detection, Video & Audio Analytics, Network Disconnect
• Alarm Events- File upload via FTP and E-Mail, Notification via E-Mail, TCP and HTTP, local storage SD/SDHC/SDXC) or NAS recording at Alarm Triggers, External output, Preset
• Pixel Counter- Support

Network

• Ethernet- RJ-45 (10/100BASE-T)
• Video Compression Format- H.265 / H.264 (MPEG-4 part 10/AVC), Motion JPEG
• Resolution- 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240
• Max. Framerate- H.265 / H.264 : Max 60fps at all resolutions, Motion JPEG : Max. 30fps at all resolutions
• Smart Codec- Manual mode (Area-Based : 5ea)
• WiseStreamII- Support
• Video Quality Adjustment- H.265 / H.264 / MJPEG : Target Bitrate Level Control
• Bitrate Control Method- H.265 / H.264 : CBR or VBR, Motion JPEG : VBR
• Streaming Capability- Multiple Streaming (Up to 10 Profiles)
• Audio In- Selectable (Mic IN / Line IN) Supply voltage : 2.5VDC (4mA), Input impedance: approx. 2K Ohm
• Audio Out- Line out (3.5mm mono jack), Max output level : 1 Vrms
• Audio Compression Format- G.711 u-law /G.726 Selectable, G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 16KHz
• Audio Communication- Bi-dierctional (2-Way)
• IP- IPv4, IPv6
• Protocol- TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
• Security- HTTPS(SSL) Login Authentication, Digest Login Authentication, IP Address Filtering, User access Log, 802.1X Authentication (EAP-TLS, EAP-LEAP)
• Streaming Method- Unicast / Multicast
• Max. User Access- 20 users at Unicast Mode
• Edge Storage- Micro SD/SDHC/SDXC 2slot (up to 512 GB) - Continuous recording (1'st slot to 2'nd slot)- Motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded. NAS (Network Attached Storage), Local PC for Instant Recording
• Application Programming Interface- ONVIF profile S/G, SUNAPI 2.0 (HTTP API), Wisenet Open Plarform
• Webpage Language- English, French, German, Spanish, Italian, Chinese, Russian, Japanese, Swedish, Portuguese, Turkish, Polish, Czech, Dutch, Hungary, Greek
• Web Viewer- Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10. 10.11 10.12 Plug-in Free Webviewer Supported Browser : Google Chrome, MS Edge, Mozilla Firefox (Window 64bit only), Apple Safari 10 (Mac OS X only) Plug-in Webviewer Supported Browser : MS Explore 11, Apple Safari 10 (Mac OS X only)
• Central Management Software- SmartViewer, SSM

Environmental

• Operating Temperature / Humidity- -22°F ~ +131°F (-30°C ~ +55°C) / Less than 90% RH
• Storage Temperature / Humidity- -22°F ~ +140°F (-30°C ~ +60°C) / Less than 90% RH
• Ingress Protection- IP66
• Vandal Resistence- IK10

Electrical

• Input Voltage / Current- 12V DC, PoE
• Power Consumption- 12W

Mechanical

• Color / Material- Ivory / Aluminum
• Dimensions (WxH)- Ø6.61" x 6.36" (Ø168.0 x 161.5mm)
• Weight- 4.19 lb (1.9 kg)
