N16NRX40TB Speco Technologies NRX Series 16 Channel NVR 192 Mbps Max Throughput - 40TB w/ Built-in 16 PoE Ports

Specifications

Video

Input

• Max. IP Channels - 16
• IP Camera - H.265/H.264 auto detection (max. 16MP)

Output

• Main Monitor - HDMI (max. 4K) and VGA (max. Full HD)

Audio

• Network Input - 16-CH IPC audio input
• Local Input - RCAx1
• Local Output - RCAx1

Recording

• Encoding Resolutions - 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P
• Codec - H.264/H.265 (auto detection)
• Max Frame Rate per Channel - 16MP @ 30fps
• Recording Mode - Analytics/continuous/motion/sensor/schedule/manual
• Pre-Recording - Max. 5 seconds
• Post Recording - Max. 10 minutes

Search & Playback

• Search - EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log
• Simultaneous Playback - Max 16-CH
• Smart Search - Highlighted color to display camera records in a certain period of time, different colors refer to different record events
• Playback Functions - Play, pause, fast forward, rewind, digital zoom, etc

Backup

• Media - USB drive, network
• Format - MP4, JPG, AVI, proprietary format (includes player)

Storage

• HDD Max Capacity of each HDD - 40TB
• HDD Internal SATA ports - 2
• USB-Front - 1 (USB 2.0)
• USB-Rear - 1 USB 2.0, 1 USB 3.0

Alarm

• Mode - Manual, sensor, motion, exception, intelligence
• Input - 8-CH local
• Output - 4-CH local
• Linkage - Record/snapshot/preset/email/pop-up window

User I/F

• Input Method - IR remote, mouse

Network

• Network Bandwidth - 192Mbps
• P2P/Dynamic DNS - Free US-Based Speco P2P and DDNS service
• Network Protocols - TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP

Network Access

• Mobile - iOS/Android via Speco Blue App, SecureGuard Client
• Web Viewer - Google Chrome, Microsoft Edge, Firefox, Safari
• VMS/CMS - Speco Blue VMS, SecureGuard
• Max. User Access - Max 10 users online (web client)

Features

• Digital Zoom - Live and playback, free size
• Fisheye Dewraping* - Yes
• S.M.A.R.T (Self-Monitoring, Analysis & Reporting Technology) - Temperature, power on time, bad sectors, and health

Smart Analytics

• People/Vehicle Detection - Line crossing and intrusion
• Facial Detection - Face search up to 8-CH (N8NRX) and up to 16-CH
• LPR - 16-CH

Power

• Power Consumption - ≤ 15W (without HDD)
• PoE Ports - 16
• Power per PoE Port Max (802.3at) - 30W
• Total PoE Power Budget (802.3af/at) - 150W

Environment

• Operating Temperature - 14°F to 122°F (-10°C to 50°C )
• Operating Humidity - 10% ~ 90% humidity

Dimensions

• Unit - 380mm x 268mm x 45mm (15.0” x 10.6” x 2.0”)

N16NRX40TB Specifications PDF
