O4BXLP1M Speco Technologies 8-32mm Motorized 30FPS @ 4MP Indoor/Outdoor Day/Night Box IP License Plate Recognition Security Camera 24VDC/POE

Specifications

Camera Specifications

• Image Sensor – 1/1.8" Progressive Scan CMOS
• Maximum Resolution – 2560 x 1520 (4MP)
• Field of View – Horizontal: 41°~15.5° Vertical: 23°~9.5° Diagonal: 46.5°~18°
• Minimum Illumination – 0 lux with white LED
• White Balance – Auto, Indoor, Outdoor, Manual
• Day/Night – White LED
• Electronic Shutter Speed – 1s ~ 1/100000s
• DNR – 3D DNR
• Angle Adjustment – Pan: 0°~360° Tilt:0°~90° Rotation: 0°~360°

System Specifications

• PoE – Standard (IEEE 802.3bt)
• Analytics – License plate recognition, travel direction, vehicle metadata, video tampering detection
• Image Settings – Region of interest, saturation, brightness, chroma, contrast, noise reduction, corridor mode, video masking

Interfaces

• Ethernet – 10/100 Mbps RJ45
• Power – 24V AC/DC wire input
• Microphone Input – Yes, 1-CH
• Audio output – Yes, 1-CH
• Card slot – MicroSD, up to 256GB (not included)
• Alarm – 2-CH alarm input; 2-CH alarm output
• CVBS Out – Yes, 1-CH
• Wiegand – Yes, 26-bit
• RS485 – Yes
• RS232 – Yes
• Reset – Yes

Network Specifications

• Protocols – UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS
• DDNS support – Speco DDNS (free of charge)
• Security – Watermark, IP address filtering, video mask, heartbeat, password protection, non-photosensitive switch, image distortion correction
• User Access – Max. 10 simultaneous users Actual number of users may vary depending on bandwidth

Operating & Unit Specifications

• Power – PoE++, 24V AC/DC (power supply not included)
• Power Consumption – 21.5W (max)
• Operating Temperature – -40°F ~ 140°F
• Operating Humidity – Less than 95% (non-condensing)
• Unit dimensions – 16.9"(L) x 5.43"(W) x 4.25"(H)
• Unit Weight – 5.51 lbs.
• Certifications – FCC

Video Specifications

• Main Resolution – 4MP/2K/3MP/1080P (up to 30fps); HFR Mode: 1080P/720P (1 ~ 60fps)
"
• Sub Stream – 720P/D1/CIF (up to 30fps)
• Third Stream – D1/CIF (up to 30fps)
• Compression – H.265, H.264, MJPEG
• Bitrate Control – VBR, CBR (64 Kbps ~ 8 Mbps)
• Multiple Streaming – 3 streams

Client Specifications

• Web Browser Support – Chrome, Edge, Safari, Firefox, Internet Explorer 8 and up
"
• PC Application – SecureGuard® VMS SecureGuard® CMS Speco Blue VMS
• Mobile – Speco Blue App, SecureGuard® App (iPhone® and Androidâ„¢)

Audio Specifications

• Audio Compression – G.711A / G.711U
• Audio Interface – 1-CH in/ 1-CH out

8 - 32mm Lens Installation Recommendations

• Overhead – Recommended Installation Height: 15 ~ 20 ft. Recommended Recognition Distance: 23 ~ 115 ft.
• Entrance/Exit – Recommended Installation Height: 4.2 ~ 5 ft. Recommended Recognition Distance: 8 ~ 10 ft.
