O4VB1NG Speco Technologies 2.8mm 30FPS @ 4MP Outdoor IR Day/Night WDR Bullet IP Security Camera 12VDC/PoE

Specifications

Camera

• Image Sensor - Progressive scan 1/3" CMOS, 4MP
• Maximum Resolution - 2560 x 1440 (4MP)
• Field of View (H) - 102.5° (H), 55° (V), 122°(D)
• Minimum Illumination - 0.005 lux @ F1.6, AGC ON; 0 lux with IR
• Image Settings - Region of interest, Saturation, Chroma, Contrast, Wide Dynamic, Defog, Sharpen, Noise Reduction
• Day/Night - Smart IR up to 100' (depending on scene reflection)
• Compensation - True WDR, BLC, HLC
• Electronic Shutter Speed - 1/2 - 1/100000 sec
• DNR - 3D DNR
• Angle Adjustment - Pan 0°-360°, Tilt 0°-80°, Rotation 0°-360°

Video

• Main Resolution - 2560x1440 / 2304x1296 /1920x1080 @ 30fps
• Sub Stream Resolution - 720p (1-15fps), D1, CIF (1-30fps)
• Thirs Stream - D1, CIF, 480x240 (1-30fps)
• Compression - H.265, H.264
• Bitrate Control - VBR, CBR (64 Kbps ~ 5 Mbps)
• Multiple Streaming - 3 streams

Network

• Protocols - UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, 802.1x, UPnP, HTTP, HTTPS, QoS
• DDNS support - Speco DDNS (free of charge)
• Security - User ID & Password protection, IP/Mac address filtering, digest authentication
• User Access - Max. 4 simultaneous users, Actual number of users may vary depending on bandwidth

Interfaces

• Ethernet - RJ45 Jack
• Power - DC jack
• Audio Input - 3.5mm input
• Audio Out - No
• Card Slot - MicroSD, up to 256GB (not included)
• Alarm In/Out - No
• Reset - Yes

System

• PoE - Standard (IEEE 802.3af)
• Analytics - Line crossing, object detection, region intrusion and video blurring detection
• Alarm Triggers - Motion, Analytics, SD card error
• Image Settings - Watermark, IP address filtering, video mask, password protection, Corridor mode

Client

• Web Browser Support - Chrome, Edge, Safari, Firefox, Internet Explorer
• PC Application - SecureGuard VMS; SecureGuard CMS
• Mobile - SecureGuard Client; Speco Blue (iPhone and Android)

Operating & Unit

• Power - PoE, 12VDC (power supply not included)
• Power Consumption - < 5W
• Operating Temperature - -40°F ~ 140°F
• Operating Humidity - Less than 95 % (non-condensing)
• Unit Dimensions - 2.93" (W) x 2.93" (D) x 6.59" (H)
• Unit Weight - 0.93 lb
• Certifications - FCC

O4VB1NG Specifications PDF
