O4VT2G Speco Technologies 2.8mm 30FPS @ 4MP IR Day/Night WDR Line Crossing Turret IP Security Camera 12VDC/POE

Specifications

Camera Specifications

• Image Sensor – Progressive scan 1/3” CMOS, 4MP
• Maximum Resolution – 2560 x 1440 (4MP)
• Field of View – 94° (H), 50° (V), 115° (D)
• Minimum Illumination – 0.005 lux @ F1.6, AGC ON; 0 lux with IR
• Image Settings – Region of interest, saturation, brightness, chroma, contrast, wide dynamic, defog, sharpen, noise reduction
• Day/Night – Smart IR up to 167’ (depending on scene reflection)
• Compensation – True WDR, BLC, HLC
• Electronic Shutter Speed – 1/2 - 1/100000 sec.
• DNR – 3D DNR
• Angle Adjustment – Pan 0°-360°, Tilt 0°-75°, Rotation 0°-360°

Client Specifications

• Web Browser Support – Google Chrome, Edge, Safari, Firefox, Windows (Internet Explorer 8 and up)
• PC Application – Speco Blue VMS, SecureGuard® CMS
• Mobile – SecureGuard® Client, Speco Blue (iPhone® and Android™)

Interfaces

• Ethernet – RJ45 Jack
• Power – DC jack
• Audio Input – 3.5mm input, built-in mic
• Audio Out – No
• Card Slot – MicroSD, up to 256GB (not included)
• Alarm – No
• Reset – Yes

Audio Specifications

• Audio Codec – G.711A / G.711U

Network Specifications

• Protocols – UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, 802.1x, UPnP, HTTP, HTTPS, QoS
• DDNS Support – Speco DDNS (free of charge)
• Security – User ID & password protection, IP/Mac address filtering, digest authentication
• User Access – Max. 4 simultaneous users; actual number of users may vary depending on bandwidth

Video Specifications

• Main Resolution – 2560x1440 / 2304x1296 / 1920x1080 @ 30fps
• Sub Stream – 720p (1-15fps), D1, CIF (1-30fps)
• Third Stream – D1, CIF, 480x240 (1-30fps)
• Compression – H.265, H.264
• Bitrate Control – VBR, CBR (64Kbps ~ 10Mbps)
• Multiple Streaming – 3 streams

System Specifications

• PoE Standard – IEEE 802.3af
• Analytics – Line crossing, object detection, region intrusion, people/vehicle detection and video blurring detection
• Alarm Triggers – Motion, detection events, SD card error
• Image Settings – Watermark, IP address filtering, video mask, password protection

Operating & Unit Specifications

• Power – PoE, 12VDC (power supply not included)
• Power Consumption – < 5W
• Operating Temperature – -40°F ~ 140°F
• Operating Humidity – Less than 95% (non-condensing)
• Unit Dimensions – 4.2” (Dia.) x 3.75” (H)
• Unit Weight – 1.0 lb.
• Certifications – FCC
