O2P25X Speco Technologies 2MP 25x Indoor/Outdoor IP PTZ Camera

Camera Specifications

• Image Sensor - Progressive scan 1/2.8" CMOS, 2M pixels
• Maximum Resolution - 1920 x 1080
• Minimum Illumination - Color: 0.005 Lux, B/W 0.001 Lux @ (F1.65, AGC ON);0 Lux with IR
• Field of View (H) - Horizontal: 57.6° ~ 2.5°; Vertical: 34.4° ~ 1.4°; Diagonal: 64.5°~2.9°
• Image Settings - Flip, Mirror, Saturation, Brightness, Contrast, Sharpness
• Compensation - True WDR, BLC, HLC
• Day/Night - Smart IR with cut filter
• Electronic Shutter Speed - 1s ~ 1/100,000s
• DNR - 3D DNR
• Angle Adjustment - Pan: 0°~360°; Tilt: -5° ~ 90°

Video Specifications

• Main Stream Resolution - 1080P, 720P (up to 30fps)
• Sub Stream Resolution - 720P, 704x480, 352x240 (up to 30fps)
• Third Stream - 704x480, 640x480, 352x240 (up to 30fps)
• Compression - H.265, H.264. MJPEG
• Multiple Streaming - 3 streams

Interfaces

• Network - RJ45 jack
• Power - DC jack (12V)
• Card Slot - MicroSD, up to 256GB (card not included)
• Reset - Yes

Network Specifications

• Protocols - HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE
• DDNS Support - Speco DDNS (No fee)
• Security - User ID & Password protection, IP/MAC address filtering, digest authentication
• User Access - Max. 6 simultaneous users (Actual number of users may vary depending on bandwidth)

System Specifications

• PoE - PoE+ (IEEE 802.3at)
• Analytics - People & Vehicle Detection, Intrusion Detection, Line Crossing Detection, and People & Vehicle Counting
• Exception Detection - Video tampering detection
• Alarm Triggers - Motion, Analytics, SD card error
• Image Settings - Watermark, IP address filtering, video mask, password protection
• Action Modes - Preset/Cruise/Track/Auto Scan/Random Scan

Client Specifications

• Web Browser Support - Windows (Internet Explorer 8 and up)
• PC Application - SecureGuard VMS, SecureGuard CMS
• Mobile - SecureGuard Client (iPhone and Android), Speco Blue

Operating & Unit Specifications

• Power - PoE+ (IEEE 802.3at), 12VDC (power supply included)
• Power Consumption - 22W (max)
• Operating Temperature - -22°F - 131°F (-30°c – 55°c)
• Operating Humidity - less than 95% (non-condensing)
• Unit Dimensions - 6.8" (Φ) x 9.7" (H); Φ 173mm x 247mm
• Unit Weight - 4.63 lb (2.1kg)
• Certifications - IP66, FCC
