O4P4X2 Speco Technologies 2.8-12mm Optical Zoom 30FPS @ 2592 x 1520 Outdoor Day/Night WDR PTZ IP Security Camera 12VDC/PoE

Specifications

Camera Specifications

• Image Sensor – Progressive scan 1/2.7” CMOS, 4MP
• Maximum Resolution – 2592 x 1440
• Minimum Illumination – Color: 0.01 Lux, B/W 0.002 Lux @ (F1.6 AGC ON); 0 Lux with IR
• Field of View – Horizontal: 97° ~ 31°; Vertical: 51° ~ 18°; Diagonal: 115°~36°
• Compensation – True WDR (120dB) / BLC / HLC
• Day/Night – Smart IR with cut filter
• Electronic Shutter Speed – 1/30s - 1/30000s
• DNR – 3D DNR

Video Specifications

• Main Resolution – 2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720 (up to 30fps)
• Sub Stream Resolution – 704×480, 640×480, 352×240 (up to 30fps)
• Thirs Stream Resolution – 1280 x 720, 704×480, 640×480, 352×240 (up to 30fps)
• Compression – H.265, H.264, MJPEG
• Bit Rate – 64Kbps ~ 16Mbps
• Multiple Streaming – 3 streams

PTZ Specifications

• Pan Range – 0°- 355°
• Tilt Range – -5° - 90°

Network Specifications

• Protocols – HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE
• DDNS Support – Speco DDNS (free of charge)
• Security – User ID & Password protection, IP address filtering
• User Access – Max. 16 simultaneous users (Actual number of users may vary depending on bandwidth)

Client Specifications

• Web Browser Support – Chrome, Edge, Safari, Firefox, Windows (Internet Explorer 8 and up)
• PC Application – SecureGuard® VMS, SecureGuard® CMS
• Mobile – SecureGuard® Client (iPhone® and Android™), Speco Blue App

Interfaces

• Ethernet – RJ45 Jack
• Power – DC Jack
• Audio – 3.5mm in/3.5mm out
• Card Slot – MicroSD, up to 256GB (not included)
• Alarm In/Out – 1 ch in/1 ch out
• Reset – Yes

System Specifications

• PoE – PoE+ (IEEE 802.3at)
• Analytics – Face, People and Vehicle Detection, Object Removal Detection, Intrusion, Line crossing
• Alarm Triggers – Motion, Analytics, SD card error
• Image Settings – Watermark, IP address filtering, video mask, password protection
• Action Modes – Preset/Cruise/Track/Auto Scan/Random Scan

Operating & Unit Specifications

• Power – PoE+ (IEEE 802.3at), 12VDC 3A (power supply not included)
• Power Consumption – 24.5W max.
• Operating Temperature – -22°F - 131°F
• Operating Humidity – less than 95% RH
• Unit Dimensions – 5.1” (Dia.) x 6.4” (H)
• Unit Weight – 2.7 lbs.
• Certifications – FCC
