O8P32X Speco Technologies 4.8 – 154mm 32x Optical Zoom 30FPS @ 8MP Indoor/Outdoor IR Day/Night WDR PTZ IP Security Camera 24VDC/24VAC/POE

Specifications

Camera Specifications

• Image Sensor - 1/2.8” SONY® latest progressive scan CMOS
• Maximum Resolution - 3840 x 2160 (8MP)
• Field of View
• Horizontal - 61.3° ~2.18°
• Vertical - 36.9° ~ 1.22°
• Diagonal - 68.4° ~ 2.5° ±5%
• Minimum Illumination - Color: 0.01 Lux@(F1.3, AGC ON); B/W: 0.002Lux@(F1.3, AGC ON); 0 Lux with IR
• Image Settings - Flip, Mirror, Saturation, Brightness, Contrast, Sharpness
• Compensation - True WDR, BLC, HLC
• Day/Night - Smart IR with cut filter
• Electronic Shutter Speed - 1/30s ~ 1/30,000s
• DNR - 3D DNR
• Angle Adjustment - Pan: 0°~360°; Tilt: -25° ~ 155°
• Cruise/Presets - 8 cruises, up to 16 presets for each cruise

Video Specifications

• Main Stream Resolution - 3840x2160, 2560x1440, 1920x1080,1280x960, 1280x720 (1~30fps)
• Sub Stream Resolution - 704x480, 640x480, 352x240 (1~30fps)
• Third Stream - 1920x1080, 1280x960, 1280x720, 704x480, 640x480, 352x240 (1~30fps) Compression H.265, H.264. MJPEG
• Compression - H.265, H.264. MJPEG
• Multiple Streaming - 3 streams

Interfaces

• Network - RJ45 jack (PoE++)
• Power - 24VDC jack
• Microphone Input - 3.5mm
• Audio output - 3.5mm
• Card slot - MicroSD, up to 256GB (card not included)
• Alarm - 1-CH alarm input; 1-CH alarm output
• Reset - Yes

Network Specifications

• Protocols - HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/ IP, UDP, IGMP, ICMP, DHCP, PPPoE
• DDNS support - US-based Speco DDNS (No fee)
• Security - User ID & password protection, IP/MAC address filtering, digest authentication
• User Access - Max. 16 simultaneous users (Actual number of users may vary depending on bandwidth)

Client Specifications

• Web Browser Support - Chrome, Edge, Safari, Firefox, Windows (Internet Explorer 8 and up)
• PC Application - Speco Blue VMS, SecureGuard® VMS, SecureGuard® CMS
• Mobile - Speco Blue app, SecureGuard® App (iPhone® and Android™)

Audio Specifications

• Audio Compression - G.711A / G.711U

System Specifications

• PoE - PoE++ (IEEE 802.3bt)
• Detection events - Motion, Line crossing, Intrusion (people/vehicle/non-motor vehicle classification), face detection, video tampering
• Alarm Triggers - Detection events, Sensor alarm, SD card error
• Image Settings - Watermark, IP address filtering, video mask, password protection
• Action Modes - Preset/Cruise/Track/Auto Scan/ Random Scan

Operating & Unit Specifications

• Power - PoE++ (IEEE 802.3bt), 24V AC/DC (PoE Injector included)
• Power Consumption - 34W (max)
• Operating Temperature - -40°F - 149°F (-40°c – 65°c)
• Operating Humidity - Less than 95% (non-condensing)
• Unit Dimensions - 7.7” (w) x 12.5” (H); 196mmx317mm
• Unit Weight - 8.31 lb (3.7kg)
• Certifications - IP67, FCC, RoHS
