ESUGS4-EG1-P1 KBC Industrial 6 Port PoE+ Ethernet Switch 4 Port 802.3at LAN w/ 2 Uplink Ports

The KBC ESUGS4-EG1-P1 series is a high performance, industrial gigabit switch with 4 gigabit IEEE 802.3af/at Ethernet ports, 1 optical gigabit port and 1 gigabit Ethernet ports. It is lite managed and provides broadcast storm protection.

Specifications

Standards

• IEEE Standards - IEEE802.3, IEEE802.3u, IEEE 802.1ab, IEEE802.3z, IEEE 802.3x

Ports

• Electrical - 5 x 10/100/1000Base-T
• Optical - 1 x 1000Mbps SFP (1)

Switch Performance

• Architecture - Store-and-forward
• Jumbo Frame - 9 kbytes

PoE

• Standard - 802.3af/at
• PSE Type - End-span
• Power Pin Assignment - 1/2(+), 3/6(-)
• PoE Power Output - 30 watts max. per port

Power (2)

• Power Input - 48Vdc
• Power Consumption - ≤ 2W (No POE output)
• Power Budget - 90W
• Power Fault - Relay Output, 1 A @ 24 Vdc

Protection

• Reverse - Provided
• Overcurrent - Provided

Environmental

• Operating Temperature - -40° ~ +75°C (-40 ~ 167°F)
• Storage Temperature - -40° ~ +85°C (-40 ~ 185°F)
• Operating Humidity - 10% to 95% non-condensing

Mechanical

• Dimension (WxHxD) - 30 x 140 x 95 mm, 1.18" x 5.51" x 3.74"

Connectors

• 10/100/1000 Electrical - RJ45
• Optical - SFP (Small Form-factor Pluggable)
• Power - 6-pin screw Terminal Block (including relay)

ESUGS4-EG1-P1 Specifications PDF
