[DISCONTINUED] IPHEBX2-3-W Rainvision 2.8mm 30FPS @ 1080p Outdoor IR Day/Night WDR Eyeball IP Security Camera 12VDC/PoE - White

Specifications

Camera

• Image Sensor - 1/2.8" Progressive Scan CMOS
• Min. Illumination - 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Speed - 1/3 s to 1/10,000 s
• Lens - 2.8mm @ F.20
• Lens Mount - M12
• Day & Night - IR cut filter with auto switch
• DNR - 3D DNR
• Wide Dynamic Range - 120dB
• Angle Adjustment - Pan: 0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360°

Compression Standard

• Video Compression - H.264 / MJPEG/H.264+
• H.264 Type - Main Profile
• Video Bit Rate - 32 Kbps ~ 16 Mbps
• Dual streams - Support


• Max. Resolution - 1920 x 1080
• Frame Rate - 50Hz: 25fps (1920 x 1080), 25fps (1280 x 960), 25fps (1280 x 720), 60Hz: 30fps (1920 x 1080), 30fps (1280 x 960), 30fps (1280 x 720)
• Image Setting - Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
• BLC - Support, zone configurable
• ROI Codec - Support

Network

• Network Storage - NAS (Support NFS,SMB/CIFS), ANR
• Alarm Trigger - Intrusion detection, Line crossing detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
• Protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjou
• General - Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access
• Standard - ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI

General

• Operating Conditions - -22 °F ~ 140 °F, Humidity 95% or less (non-condensing)
• Power Supply - DC12V ± 10%, PoE (802.3af)
• Power Consumption - Max. 5.5W (Max. 7.5W with ICR on)
• IR Range - 98 Feet
• Ingress Protection - IP66
• Dimensions - 5.0" x 3.8"
• Weight - 1.5 lbs
• Warranty - 3 Years
• Package Contents - Camera, Installation CD / Manual / Template, Mounting Screws, Weathertight Connector

IPHEBX2-3-W Specifications PDF
