PAR-P8DRIR28-LC2 InVid Tech Paramont Series 2.8mm 20FPS @ 8MP Outdoor IR Day/Night WDR Dome IP Security Camera 12VDC/PoE

Camera Specifications

• Image Sensor - 1 / 2.8 "CMOS
• Image Size - 3840x2160
• Electronic Shutter - 1 s ~ 1 / 100000 s
• Iris Type - DC Iris
• Min. Illumination - 0.02 lux @ F1.6, AGC ON; 0 lux with IR, 0.01 lux @ F1.2, AGC ON; 0 lux with IR
• Lens - 2.8~12mm@F1.6, motorized
• Field of View - Horizontal:102°~32.1°; Vertical :69.6°~18.4°; Diagonal:109.6°~36.5°
• Lens Mount - 014
• Day&Night - ICR
• Wide Dynamic Range - 120db
• BLC - Yes
• HLC - Yes
• Defog - Yes
• Digital NR - 3D DNR
• Angle Adjustment - Pan: 0°~345°; Tilt:0°~77°; Rotation: 0°~345°

DORI Distance

• Lens - 2.8mm
• Detect (ft) - 284.3 (86.7m)
• Observe (ft) - 113.7 (34.7m)
• Recognize (ft) - 56.9 (17.33m)
• Identify (ft) - 28.41(8.7m)


• Video Compression - H.265+ / H.265 / H.264+ / H.264 / MJPEG
• H.264 Compression Standard - Baseline Profile/Main Profile/High Profile
• Resolution - 8MP ( 3840 x 2160 ), 6MP( 3072 x 2048 ),5MP( 2592 x 1944), 4MP ( 2560 x 1520), 2K(2560 x 1440 ), 3MP(2304 x 1296), 1080P ( 1920 x 1080 ), 720P ( 1280 x 720 ), D1, CIF, 480 x 240
• Main Stream - 60Hz : 8MP(1~20fps)/6MP/5MP/4MP/2K/3MP/1080P/720P(1~30fps), 50Hz : 8MP(1~20fps)/6MP/5MP/4MP/2K/3MP/1080P/720P(1~25fps)
• Sub Stream - 60Hz: 720P(1~12fps)/D1/480 x 240(1~30fps), 50Hz: 720P/D1/480 x 240(1~25fps)
• Third Stream - 60Hz: D1/CIF/480 x 240 (1~30fps), 50Hz: D1/CIF/480 x 240 (1~25fps)
• Bit Rate - 64 Kbps ~ 12 Mbps
• Bit Rate Type - VBR / CBR
• Audio Compression - G711A / U
• Image Settings - ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, image mirror, image flip, Sharpness, NR, etc. adjustable through client software or web browser
• ROI - Each ROI to be configured separately

Interfaces

• Network - RJ45
• Video Output - No
• Audio - 1CH built-in MIC; 1CH audio input
• Storage - Built-in micro SD card slot, up to 256GB
• Hardware Reset - Yes
• Audio Sensitivity - - 36db

Functions

• Remote Monitoring - Web browser/ Paramont DVR&NVR / Paramont CMS / Paramont CMS App
• Online Connection - Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission
• Network Protocol - UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP,HTTP, 802.1x, UPnP, HTTPs, QoS
• Interface Protocol - ONVIF Profile T
• Storage - Network remote storage; micro SD card storage
• Smart Alarm - Motion detection; SD card error; SD card full
• Intelligent Analytics - Scene change, video blur detection, video color cast detection, line crossing detection, intrusion detection
• General Function - Watermark, IP address filtering, video mask, heartbeat, password protection, corridor pattern, etc.
• PoE - Yes (IEEE802.3af)
• IR Distance - 98' (20~30m)
• Ingress Protection - IP67 & IK10

Others

• Power Supply - DC12V/PoE
• Power Consumption - < 7W
• Storage Conditions - -22°F~149°F (- 30 °C ~ 65°C), Humidity: less than 95 % (non-condensing)
• Operating Environment - -22°F~140°F (- 30 °C ~ 60 °C), Humidity: less than 95 % (non-condensing)
• Dimensions - Ø4.7 x 3.5 in (Ø 119 × 87.8mm)
• Weight ( net ) - Approx. 1.4 lbs (0.64KG)
• Installation - Ceiling mounting; Wall mounting
• Certificate - CE, FCC, ETL: 5025761
• Environmental Protection - Complies with Directive EU RoHS, WEEE(2012/19/EU), directive 94/62/EC and REACH(EC1907/2006)

PAR-P8DRIR28-LC2 Specifications PDF
