TCT-8MP-E2 Nuvico Xcel Series 2.8mm Lens 15FPS @ 8MP/4K Indoor/Outdoor IR Day/Night Eyeball HD-TVI/HD-CVI/AHD/Analog Security Camera 12VDC

Specifications

Video

• Image Sensor - 1/2.5" CMOS
• Image Size - 8MP (3840 x 2160)
• Lens - 2.8mm, Fixed
• Video Output - HD-TVI / HD-CVI / AHD / CVBS
• Image System - NTSC/PAL
• Electronic Shutter - Auto
• IR Distance - Up to 100 ft.
• Frame Rate - 15fps
• Min. Illumination - Color: 0.01 lux @ F1.2, AGC ON; BW: 0 Lux with IR ON
• S / N Ratio - ≥52dB ( AGC OFF )

Functions

• Function Control - OSD Menu w/ Control over Coax
• Day & Night - ICR
• Digital WDR - Yes
• Auto White Balance - Yes
• BLC - Yes
• Saturation - Yes
• Sharpness - Yes
• Contrast - Yes
• Smart IR - Yes
• Image Setting - Yes
• Defect Correction - Yes
• Language - English / Chinese
• Angle Adjustment - Pan: 0°~360°, Tilt: 0°~75°, Rotation: 0°~360°

General

• Power Requirement - 12VDC ( ± 10% )
• Power Consumption - IR Off: < 1W; IR On: < 4.5W
• Protection - IP67
• Working Environment - -22°F ~ 122°F
• Relative Humidity - 10% ~ 90%
• Weight - .86 lbs
• Dimensions - Ф3.72" x 3.26"
• Warranty - 3 Years
• Package Contents - Camera, Installation Manual/Template, Installation Accessories
