GV-GEBF4911+256G Geovision 2.8~12mm Motorized 30FPS @ 4MP Outdoor White Light WDR Eyeball IP Security Camera 12VDC/PoE with 256GB Micro SD

GV-GEBF4911 is an outdoor eyeball dome IP camera equipped with smart warm LEDs for full color surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. GV-GEBF4911 adheres to IK10 and IP66 standards, and can be powered through PoE.

Specifications

Camera

• Image Sensor - 1/3" progressive scan CMOS
• Picture Elements - 2592 (H) x 1520 (V)
• Minimum Illumination
  • Color - 0.02 Lux (F1.4, AGC ON)
• Shutter Speed - Automatic / Manual (1/3 ~ 1/100000 sec)
• White Balance - Automatic, Manual
• Gain Control - Automatic, Manual
• S/N Ratio - 50 dB
• WDR - WDR Pro
• Dynamic Range - 120 dB

Lens

• Megapixel - 4MP
• Day / Night - Yes (with removeable IR-cut filter)
• Lens Type - Motorized
• Focal Length - 2.8 -12 mm
• Maximum Aperture - F/1.4
• Mount - Ø 14
• Horizontal FOV - 96° - 32.33°
• Operation
  • Focus - Auto / Manual Zoom 4.3x
  • Iris - Fixed
• Active Deterrence LED - 1 red and blue LED
• IR LED
  • Quantity - 1 IR LED
  • Max. IR Distance - 40 m (130 ft)
• Smart Illumination
  • LED Quantity - 1 Warm LED
  • Max. LED Distance - 40 m (130 ft)

Operation

• Video Compression - H.265, H.265+, H.264, H.264+, MJPEG
• Video Streaming - Triple streams from H.265, H.264 or MJPEG
• Frame Rate
  • 30 fps at 2592 x 1520, 30 fps at 2560 x 1440, 30 fps at 2304 x 1296, 30 fps at 1920 x 1080, 30 fps at 1280 x 720, 30 fps at 704 x 480, 30 fps at 640 x 480, 30 fps at 352 x 240, 30 fps at 480 x 240 (60 Hz)
  • 25 fps at 2592 x 1520, 25 fps at 2560 x 1440, 25 fps at 2304 x 1296, 25 fps at 1920 x 1080, 25 fps at 1280 x 720, 25 fps at 704 x 567, 25 fps at 640 x 480, 25 fps at 352 x 288, 25 fps at 480 x 240 (50 Hz)
  • *The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)
• Video Analytics - Motion Detection, Video Exception Detection (Scene Change, Video Blur and Abnormal Color Detection), Object Abandoned/Missing Detection
• Image Setting - Brightness, Contrast, Saturation, Sharpness, Antiflicker, 3D Noise Reduction, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270°‐including Corridor format)
• Audio Compression - G.711
• Audio Support - Two-way Audio
• Digital I/O
  • Input - 1 input, dry contact, NO/NC
  • Output - 1 relay output (1A 30V DC / 0.3A 125V AC)

Video Resolution

• Main Stream - 2592 x 1520 (Default), 2560 x 1440, 2304 x 1296, 1920 x 1080, 1280 x 720
• Sub Stream - 1280 x 720 (Default), 704 x 480, 640 x 480, 352 x 240
• Third Stream (Closed by Default) - 704 x 480, 640 x 480, 352 x 240, 480 x 240

Network

• Interface - 10/100 Ethernet
• Protocol - UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP, RTMP, HTTP, 802.1x, UPnP, HTTPS, QoS, ONVIF (Profile G, S, T), API

Deep Learning Function

• AI Analytics - Line Crossing, Region Entrance, Region Exiting, Region Intrusion, Target Counting, Heat Map: Human & Vehicle classification Face Detection, Video Metadata

Mechanical

• Camera Angle Adjustment
  • Pan - 0° ~ 360°
  • Tilt - 0° ~ 75°
  • Rotate - 0° ~ 360°
• Connectors
  • Power - DC 12V, PoE (IEEE 802.3af)
  • Ethernet - RJ-45
  • Audio - Two‐way Audio (built‐in speaker and microphone, or external speaker and microphone with power supply), 1 in / out (stereo phone jack, 3.5 mm / 0.14") *The Audio In port only supports microphones with power supply
  • Digital I/O - 4‐pin terminal block pitch 3.5 mm (0.14")
  • Local Storage - Micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10) *UHS-II card type is not supported

General

• Operation Temperature - -30~ 60°C (-22 ~ 140°F)
• Humidity - 0% ~ 95% (no condensation)
• Power Source - DC 12V, PoE (IEEE802.3af)
• Max. Power Consumption - 12W
• Dimensions - Ø 111.6 x 99.3 mm (Ø 4.39" x 3.91")
• Weight - 0.64 kg (1.41 lb)
• Ingress Protection - IP66
• Vandal Resistance - IK10 for metal casing
• Certification - CE, FCC, RoHS compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or Utility
• Access from Web Browser - Live View, Playback, Video Recording, Image Quality, Bandwidth Control, Image Snapshot, Two‐way Audio, Digital Zoom, Text Overlay, Image Masking, Intelligent Mark
• Language - Czech, English, French, German, Hungarian, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Traditional Chinese

Software Applications

• Software Supported - GV-VMS (V17.4.7 or later, V18.3.2 or later), GV-Edge Recording Manager (V2.2.5 or later), GV-Control Center (V4.1.1 or later), GV-Recording Server (V2.1.0 or later), GV-Cloud VMS, GV-Center V2 (V18.3.0A or later)
• Smart Device Access - GV-Eye for iOS and Android (V3.0.2 or later)
• Live Viewing - Web Browser (IE, Edge, Chrome, Firefox, Safari), Mobile App

GV-GEBF4911+256G Specifications PDF
