AIA-C01BLK Hanwha Vision Blocked Exit Detection AI Pack

Introduction

Know instantly when exits are blocked.

The Blocked Exit Detection analytic triggers alarms whenever exit access is blocked so the obstruction can be removed quickly. This protects visitors and employees while helping building managers maintain Occupational Safety and Health Administration (OSHA) compliance.

Specifications

Application

• Type - Camera application In-app feature
• Installation - Hanwha Vision open platform v5.x.x or higher
• Solution - Blocked exit detection
• Version - WiseAI v1.02.05 or higher

Analytics

• Settings - Sensitivity, Include area setting, Minimum duration(5-60min)
• Analytics events - Blocked exit detection (Up to three areas)
• Event action(Cameras event rule setup) - When alarm trigger occurred
• File upload(image): e-mail/FTP
• Notification: e-mail
• Recording: SD/SDHC/SDXC or NAS recording at event triggers
• Alarm output
• Handover: PTZ preset, send message by HTTP/HTTPS/TCP
• Audio clip playback
• MQTT: publication

Supported devices

• Cameras - PND-A9081RV/A9081RF, PNV-A9081R, PNO-A9081R, PND-A9081RVX, PNV-A9081RX, PNB-A9001 - Firmware version : 2.21.15 or higher PND-A6081RV/A6081RF, PNV-A6081R, PNO-A6081R, PNB-A6001 - Firmware version : 2.21.08 or higher

Integration

• AI search - Genetec Security Center - 5.10 + DP 10.14 or higher, 5.11 + DP 11.3 or higher, 5.12 or higher - Hanwha Plug-in for Genetec_v1.04.00 or higher : Milestone - DP 12.2a or higher - Hanwha Plug-in for Milestone_v1.05.00 or higher
• Application Programming Interface - Hanwha Vision OpenAPI

License

• Trial version - Supported (60days) model code : AIA-C01BLK-T60/EX
• Sales version - model code : AIA-C01BLK/EX

AIA-C01BLK Specifications PDF
