WRR-P-E201W-48TB Hanwha Vision 1U Wisenet WAVE NVR 470Mbps Windows 10 IoT Max Throughput - 48TB

Specifications

System

• Video Management Software - Wave VMS
• Recording Bandwidth - Up to 470 Mbps * Bandwidth performance figures based on performance testing by Hanwha Vision using Wave VMS
• Included Licenses - 4 x Wave Professional License
• OS Drive Bays - 2 x 480GB Dual RAID 1 SSD (Internally Mounted)
• Data Drive Bays - 4 x 3.5" Front Hot Swappable Bays
• Data Storage - Up to 80TB raw storage
• RAID Support - RAID 0, 1, 5, 6, 10 (RAID 5 default configuration)
• Network Interface - 2 x RJ45 GbE (default), 2 x RJ45 + 2 x 10GbE RJ45 (optional)
• Processor - 1x Intel Xenon E-2356G
• Memory - 16GB, 2 x 8GB DDR4
• Operating System - Windows 11 IoT Enterprise LTSC 2024 / Windows Server 2022 Standard / Ubuntu 22.04 LTS
• Video Outputs - 1x HDMI, 1x VGA
• USB Ports - 2 x USB 3.2 (Front), 2 x USB 3.2 (Rear)
• Other Ports - Serial
• Keyboard & Mouse - Included
• Sliding Rail Kit - Included, with Cable Management Arm

Mechanical

• Form Factor: - 1U rack mount chassis
• Color/Material - Black/Metal
• Dimensions (WxDxH): - 17.3"(440mm) x 19.6"(498mm) x 1.7"(44mm)
• Weight: - 50 lbs (23 kg) * Weight is on chassis without HDD's

Electrical

• Power Supply: - (2) 450W 80 Plus Platinum
• Power Input - 100 - 240 VAC
• Heat Dissipation: - 1725 Max BTU/hr

Environmental

• Operating Temperature: - 50F - 95F (10C - 35C)
• Storage Temperature - -40�F to 158�F (-40? to 70?)
• Operating Humidity: - 10% to 80% RH with 29? (84.2�F) maximum dew point
• Certifications - BSMI, CE, FCC (Class A), UL/cUL equivalent (MET/Eurofins)

General

• The WRR-P-E201X series offers an affordable and reliable 1U rackmount solution for any entry level deployment. Up to 80TB of raw video-optimized storage is provided by 24/7 duty cycle SATA/SAS drives. The latest Intel Xeon Processor allows for high powered computing power, and 16GB of DDR4 RAM provides the system resources to scale as needed. A dedicated solid state drive for applications and the operating system enables fast boot and load times. Supports RAID 0, 1, 5, 6, and 10 storage configuration allowing for increased reliability, and a 5-year, on-site, Next Business Day, Keep Your Hard Drive warranty ensures peace of mind. Each server is pre-loaded with WAVE VMS and comes with 4 Professional licenses to ensure quick and easy deployment with minimum setup time. *NBD, on-site warranty time starts once the root cause of the issue(s) have been identified.

WRR-P-E201W-48TB Specifications PDF
