HV-GS970M/18PS-R-10 Hanwha Vision L3 Switch with 16 x 10/100/1000T PoE Ports and 2 x 100/1000X SFP Ports

SKU: HV-GS970M/18PS-R-10

16 x Gigabit Ethernet PoE+ 247W (L)

Features:

  • AT 16 x Gigabit Ethernet managed switch, 2 x SFP Uplink PoE+ 247W total PoE budget.
  • Optimized to use with Hanwha network camera products.
More details...
MPN: HV-GS970M/18PS-R-10
EAN: 849688024393
MSRP Price: $1,590.00
Web Price$1,590.00
Add to List
DWG Dealer Program Become a DWG Dealer to see your pricing. Dealer pricing, quoting, volume discounts, and sales support on thousands of products.


Product Details

Specifications

Product

  • 10/100/1000T (RJ-45)Copper Ports - 16
  • 100/1000X SFP Ports - 2
  • Total Ports - 18
  • POE+ Enabled Ports - 16
  • Switching Fabric - 36Gbps
  • Forwarding Rate - 26.8Mpps

Power Characteristics

Non PoE Load

  • Max Power Consumption - 21W
  • Max Heat Dissipation - 72 BTU/hr
  • Noise - 34dBA

Full PoE+ Load

  • Max Power Consumption - 330W
  • Max Heat Dissipation - 169BTU/hr
  • Noise - 42 dBA
  • Max Poe Power - 247W
  • Max Poe Ports At 15W Per Port - 16
  • Max Poe+ Ports At 30W Per Port - 8

Physical Specifications

  • WidthxDepthxHeight - 341 x 231 x 44 mm (13.42 x 9.09 x 1.73 in)
  • Weight - 3.0 kg (6.6 lb)
  • Packaged Dimensions - 43 x 36 x 15 cm (16.93 x 14.17 x 5.90 in)
  • Weight - 4.35 kg (9.6 lb)

Latency (microseconds)

  • Port Speed 10MBPS - 56μs
  • Port Speed 100MBPS - 7.9μs
  • Port Speed 1GBPS - 3.4μs

HV-GS970M/18PS-R-10 Specifications PDF
