DWC-B7553WTIRW Digital Watchdog 4mm 30FPS @ 5MP Outdoor IR Day/Night WDR Bullet HD-TVI/HD-CVI/AHD/Analog Security Camera 12VDC/24VAC

Featuring Star-Light Plus color in near-total darkness, 5MP Star-Light Plus Universal HD over Coax cameras deliver crystal-clear images and support HD-Analog, HD-TVI and HD-CVI. The weather resistant bullet cameras are IP66 rated and can be controlled via the same coax cable using UTC. All DW Universal HD over Coax cameras are engineered to work with our VMAX A1 Plus DVRs using your existing coax infrastructure for a cost effective, high resolution surveillance solution.

Specifications


• Image Sensor - 5MP 1/2.8" CMOS
• Active Pixels - 2608(H) x 1960(V)
• Scanning System - Progressive scan
• Frequency - 60Hz/50Hz
• Signal technology - Universal HD over Coax with HD-Analog, HD-TVI and HD-CVI to 5MP
• Synchronization - Internal
• Resolution - 2592(H) x 1944(V)
• Minimum scene illumination - 0.16 lux (color), 0 lux (B&W)
• Video Output - HD-Analog and HD-TVI: 5MP/1944p @ 20fps and 12.5fps, HD-Analog, HD-TVI and HD-CVI: 4MP/1440p @ 30fps

Lens

• Focal Length - 4.0mm
• Lens Type - Fixed Lens
• Field of View (FoV) - 82°
• IR Distance - 70ft range

Operational

• Shutter Mode - Auto
• Shutter Speed - 1/30-1/30,000
• Backlight (BLC) - Yes
• Star-Light (sense-up) - Off – x32
• Wide dynamic range (WDR) - Double shutter WDR
• Wide dynamic range (WDR) dB - 120dB
• Smart DNR 3D Digital Noise Reduction - 3D/2D DNR
• White balance - Yes
• Day/ Night - Auto, day (color), night (B/W)
• Mirror/ Flip - Yes
• Auto Gain Control - Max 72dB
• Motion Detection - Yes
• Privacy Zones - Yes
• Sharpness - Yes
• Gamma - 0.45
• De-fog - Yes
• RS485 / UTP Built-in - UTC

Environmental

• Operating Temperature - -4°F ~ 122°F (-20°C ~ 50°C)
• Operating Humidity - 10–90% RH (non–condensing)
• IP Rating - IP66 environmental-rated dust-tight and water-resistant
• Other Certifications - UL listed, FCC, CE, ROHS

Electrical

• Power Requirements - DC12V
• Power Consumption
  • DC12V(LED OFF): 2W (176mA)
  • DC12V(LED ON): 3.9W (333mA)

Mechanical

• Material - Aluminum Bullet Housing
• Dimensions - 6.41" x 2.51" (163 x 67.5 mm)
• Weight - 1.1lbs (0.5kg)
• Warranty - 5 year warranty

DWC-B7553WTIRW Specifications PDF
