[DISCONTINUED] GV-POE0811 Geovision 8-port Gigabit 802.3at Web Management PoE Switch

Specifications

Ports

• Number of Ports - 8 ports, 8‐port 10/100/1000BaseTX with RJ‐45 Connectors, PoE+, 2‐port SFP Open Slots

Performance

• MAC Address - 8 K
• Buffer Memory - 1.37 M bits
• Jumbo Frames - 9.6 KB
• Transmission Method - Store and Forward
• Transmission Media - 10/100BaseTX Cat. 5 UTP/STP 1000BaseT Cat. 5e, 6 UTP/STP
• Filtering/Forwarding Rates - 10 Mbps port ‐ 14,880 pps 100 Mbps port ‐ 148,800 pps 1000 Mbps port ‐ 1,488,000 pps

Smart Features

• Port Based VLAN - 16
• Tag Based VLAN - 16, VID 1~4096
• IGMP Snooping - V1 & V2
• Link Aggregation - up to 4 groups
• Quality of Service (QoS) - up to 4 queues, 802.1p, DSCP
• Port Management - Port State, Speed/Duplex, Flow Control Configuration, Port Mirroring , Broadcast Storm Control, PoE
• Administrator Management - Web Management, Password Protection, Configuration, Backup / Restore, Firmware Upgrade

Mechanical Characteristics

• LED Indicators - Per Port: Link/Act PoE Act/Status Power

Electrical Characteristics

• PoE Power - Input 100 ~ 240 V/AC, 50 ~ 60 Hz, Output IEEE 802.3at Compliant Voltage, Per Port Max. 30 watts (8 Ports at Full 15.4 W / 4 Ports at Full 30 W)
• Max. Power Consumption - 130 W

General

• Dimensions (H x W x D) - 44 x 440 x 220 mm (1.73" x 17.32" x 8.66")
• Weight - 3.3 kg (7.27 lb)
• Operating Temperature - 0°C ~ 40°C (32°F ~ 104°F)
• Storage Temperature - ‐20°C ~ 90°C (‐4°F ~ 194°F)
• Humidity - 10 to 90% RH (non‐condensing)

Standards and Regulatory

• Standards - IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX, IEEE 802.ab 1000BaseT, IEEE 802.3z 1000BaseSX/LX IEEE 802.3x Flow Control IEEE 802.3ad Port Aggregation IEEE 802.1Q VLAN Tagging IEEE 802.1p Class of Service, Priority Protocols IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.3at Power Over Ethernet (PoE+)
• Regulatory - CE, FCC Class A

GV-POE0811 Specifications PDF
