PAR-P2TEMPTABLET InVid Tech Paramont Series 2MP HD Temperature Measurement and Face Recognition Terminal

Specifications

Performance

• Model - PAR-P2TEMPTABLET
• OS - Embedded Linux
• Storage - 8Gb DDR3 +16GB EMMC

Screen

• Display Screen - 8inch LCD screen; resolution: 1280x800; contrast: 500:1
• Brightness - 500 lux
• Control Interface - I2C

Temperature Measurement

• Temperature Measuring Range - 89.6°~109.4° F (32°~43°C)
• Accuracy - ± (.54°F) 0.3°C
• Measuring Distance - 1Ft (0.3m)

Face Recognition

• Sensor - 1/2.7
• Lens - 2MP dual-lens, f=3.97mm @ F1.6
• Lens Mount - M12
• WDR - 120db
• Height Range of Face Recognition - 3.93-7.21Ft (1.2m-2.2m) (the recommended installation height is 4.75ft/1.45m)
• Face Recognition Distance - 0.98-6.56Ft (0.3m-2m)
• Recognition Mode - Face: 1：N
• Recognition Duration - ≤ 0.5 s per person
• Face Capacity - 20,000
• Recognition Accuracy - 99.70%

Supplementary Light

• Fill-in Light - Soft white light, IR light
• White Light Distance - 3.28-9.84Ft (1-3m)

Smart Linkage

• Screen Wakeup - Yes
• Light Adjustment - Yes
• Snapshot - Yes

Audio

• Two-way Talk - Yes (noise reduction and echo cancellation)
• Audio Input - 1CH built-in MIC
• Audio Output - Built-in speaker

Interface

• Network Interface - 10/100Mbps self-adaptive Ethernet port x1
• Alarm Input - 2CH
• Alarm Output - 2 CH
• Wiegand Interface - Wiegand input/output（26/34）
• RS485 - RS485x1 (half duplex)
• Door Lock Output - Relay output, NO/NC(optional), delay setting supported
• SD Card Interface - 1 micro SD card slot, up to 256G
• USB Interface - USB x1
• Anti-Tamper Interface - 1 button
• Exit Button - 1
• Reset Button - 1

Others

• Power - 12VDC@2.5A
• Power Management - Screen sleep, screen protection
• Power Consumption - <12W
• Weight - Approx. 1.2KG
• Installation - Wall Mounting，Pole Mounting, Embedded Installation, Desktop
• Protection - Surge Protection and Voltage Transient Protection
• Certifcate - CE, FCC
• Environment Protection - Complies with Directive EU RoHS, WEEE(2012/19/EU), directive 94/62/EC and REACH(EC1907/2006)
• Working Environment - 60°F~95°F，<95% (non-condensing), without wind, indoor only, 7-10 ft from opening doorways to outside or HVAC vents, no direct sunlight on the thermopile sensor or tablet screen
• Language Options - English, Espanol, Italiana, French, Deutsche, Nederlands, Hrvati, Magyar, Portuguese, Polski, Norsk & more
• Dimensions(mm) - 11.88x5.45x1.34 In (301.8x138.6x34.2mm)

PAR-P2TEMPTABLET Specifications PDF
