VIS-P4TXIR28NH-2WAY InVid Tech Vision Series 2.8mm 30FPS @ 4MP Outdoor IR Day/Night WDR Turret IP Security Camera 12VDC/POE

Specifications

Camera

• Sensor - 1/3", 4.0 megapixel, progressive scan, CMOS
• Minimum Illumination - Colour: 0.003Lux ( F1.6, AGC ON) 0Lux with light
• Day/Night - IR-cut filter with auto switch (ICR)
• Shutter - Auto/Manual, 1 ~ 1/100000s
• Adjustment Angle - Pan: 0° to 360°, Tilt: 0° to 80°, Rotate: 0° to 360°
• S/N - >52dB
• WDR - 120dB

Lens

• Lens Type - 2.8mm @1.6, Fixed-focal
• Lens Mount - M12
• Angle Of View (H) - 112.9°
• Angle Of View (V) - 59.1°
• Angle Of View (O) - 121.2°

DORI

• DORI Distance - Lens (mm) - 2.8; Detect (ft) - 206.7 (63m); Observe (m) - 82.7 (25.2m); Recognize (m) - 41.3 (12.6m); Identify (m) - 20.7 (6.3m)

Illuminator

• IR Range - Up to 98ft (30m) IR range
• White Light Range - Up to 98ft (30m) white light range
• Wavelength - IR: 850nm
• IR On/Off Control - Auto/Manual

Video

• Video Compression - Ultra 265, H.265, H.264, MJPEG
• H.264 Code Profile - Baseline profile, Main profile, High profile
• Frame Rate
  • Main Stream - 4MP (2688*1520), Max 25fps;4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps
  • Sub Stream - 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps
• Video Bit Rate - 128 Kbps~16 Mbps
• U-code - Supported
• 9:16 Corridor Mode - Supported
• OSD - Up to 4 OSDs
• Privacy Mask - Up to 4 areas
• ROI - Up to 8 areas
• Motion Detection - Up to 4 areas


• White Balance - Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
• Image Setting - Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser
• Digital Noise Reduction - 2D/3D DNR
• Smart IR - Supported
• Flip - Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
• Dewarping - N/A
• HLC - Supported
• BLC - Supported
• Defog - Digital Defog

Events

• Basic Detection - Cross line, intrusion(based on human body detection) motion detection, tampering alarm, audio detection
• General Function - Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication

Audio

• Audio Compression - G.711
• Suppression - Supported
• Sampling Rate - 8KHZ

Storage

• Edge Storage - Micro SD, up to 128GB
• Network Storage - ANR, NAS(NFS)

Network

• Protocols - IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL/TLS, 802.1x, SNMP
• Compatible Integration - ONVIF (Profile S, Profile G, Profile T), API, SDK
• User/Host - Up to 32 users. 2 user levels: administrator and common user
• Security - Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
• Client - InVid Vision (Mobile App), Vision Tools (IP Utility), InVid CMS
• Web Browser - Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below; Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+

Interface

• Network - 1 * RJ45 10M/100M Base-TX Ethernet
• Built-in Mic - Supported
• Built-in Speaker - Supported
• Audio Sensitivity - 102dB, Frequency: 550Hz~20KHz, Output: 2W

Certification

• EMC - FCC: FCC Part 15
• Safety - CE: EN 60950-1 UL: UL60950-1 IEC 60950-1

General

• Power - DC 12V±25%, PoE (IEEE 802.3af)
• Power consumption - Max 8.0W
• Power Interface - Ø 5.5mm coaxial power plug
• Dimensions (L x W x H) - Φ118 x 96mm (Φ4.6" x 3.8")
• Weight - 0.30kg (0.66lb)
• Material - Metal + Plastic
• Working Environment - -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing)
• Storage Environment - -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing)
• Surge Protection - 4KV
• Reset Button - N/A
• Ingress Protection - Ingression protection: IP67

VIS-P4TXIR28NH-2WAY Specifications PDF
