VIS-P12PANNH InVid Tech Vision Series 1.8mm Panoramic 20FPS @ 12MP Outdoor IR Day/Night DWDR Fish-Eye IP Security Camera 12VDC/POE

Specifications

Camera

• Sensor - 1/1.7", 12.0 megapixel, progressive scan, CMOS
• Minimum Illumination - Colour: 0.03Lux (F2.0, AGC ON) 0Lux with IR
• Day / Night - IR-cut filter with auto switch (ICR)
• Shutter - Auto/Manual, shutter time: 1 ~ 1/100000s
• WDR - DWDR
• S/N - >52dB

Lens

• Lens type - 1.8mm@F2.0
• Field of View - 360°

DORI

• DORI Distance
  • Lens (mm) - 1.8
  • Detect (ft) - 143.7 (43.8 m)
  • Observe (ft) - 57.4 (17.5m)
  • Recognize (ft) - 28.9 (8.8m)
  • Identify (ft) - 14.4 (4.4m)

Illuminator

• IR Range - Up to 49ft (15m) IR range
• wavelength - 850nm
• IR On/Off Control - Auto/Manual

Video

• Compression - Ultra265, H.265, H.264, MJPEG
• H.264 code profile - Baseline profile, Main Profile, High Profile
• Main Stream
  • Fisheye View: - 12MP(4000*3000)@20fps;3000*3000@20fps; 2560*2560@25fps;
  • Panorama View: - 12MP(4000*3000)@20fps;3000*2000@20/25fps; 3000*1500@20/25fp;
  • PTZ View: - 1920*1080@20/25fps;
• Sub Stream - Fisheye View:2000*1500@20fps;2000*2000@25fps
• Third Stream - Fisheye View:D1(720*576)@20/25fps;CIF352*288)@20/25fps;
• Video Bit Rate - 128 Kbps~16 Mbps
• U-code - Support
• OSD - Up to 8 OSDs
• Privacy Mask - Up to 4 areas
• ROI - Up to 8 areas
• Video stream - Triple streams

Live View Display

• Mount Type - Support table, wall, and ceiling
• Hardware Decoding
  • Ceiling mount: - fisheye view, fisheye + 4PTZ, horizontal panorama view, vertical panorama view
  • Table mount: - fisheye view, fisheye + 4PTZ, , horizontal panorama view, vertical panorama view
  • Wall mount: - fisheye view, fisheye + 4PTZ, panorama view
• Software Decoding
  • Ceiling mount: - fisheye view, 360° panorama + 1PTZ, 180° panorama view, fisheye+ 3PTZ, fisheye+4PTZ, fisheye+8PTZ,360° panorama + 6PTZ
  • Table mount: - fisheye view, 360° panorama + 1PTZ, 180° panorama view, fisheye+ 3PTZ, fisheye+4PTZ, fisheye+8PTZ,360° panorama + 6PTZ
  • Wall mount: - fisheye view, 180° panorama view, 180° panorama view+3PTZ, 180° panorama view+4PTZ, 180° panorama view+8PTZ


• White Balance - Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
• Digital noise - reduction 2D/3D DNR
• Smart IR - Support
• Flip - Normal/Flip Vertical/ Flip Horizontal/180°
• Dewarping - N/A
• HLC - N/A
• BLC - Support
• Defog - Digital Defog

Intelligent

• Smart intrusion prevention - Cross Line detection, Intrusion detection
• Statistical Analysis - Heat map(Working with management platform)

Events

• Basic Detection - Motion detection, Audio detection, Tampering alarm
• General Function - Watermark, IP Address Filtering, Tampering Alarm ,Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Audio

• Audio Compression - G.711U, G.711A
• Audio Bitrate - 64 Kbps
• Two-way audio - Support
• Suppression - Support
• Sampling Rate - 8KHZ

Storage

• Edge Storage - Micro SD, up to 256GB
• Network - Storage ANR, NAS(NFS)

Network

• Protocols - IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
• Compatible Integration - ONVIF (Profile S, Profile G, Profile T), API,SDK
• User/Host - Up to 32 users. 3 user levels: administrator, common user and operator
• Client - InVid Vision (Mobile App), Vision Tools (IP Utility), InVid CMS
• Web Browser - Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above

Interface

• Audio I/O
  • Input: - impedance 35kΩ; amplitude 2V [p-p]
  • Output: - impedance 600Ω; amplitude 2V [p-p]
• Alarm I/O - 2/1 Multiple Alarm linkage editable
• Built-in Mic - Two Mics
• Audio Sensitivity - 103dB, Frequency: 1900Hz~20KHz, Output: 2W
• Built-in Speaker - Support
• Serial - 1 channel RS485 interface
• Network - 1 RJ45 10M/100M Base-TX Auto-adaptive Ethernet
• Video Output - 1 BNC, impedance 75Ω; amplitude 1V [p-p]

Certifications

• EMC - CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019, EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
• Safety - CE LVD (EN 62368-1:2014+A11:2017), CB (IEC 62368-1:2014), UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
• Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• Protection - IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002)

General

• Power - DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 12W
• Dimensions (Φ x H) - Φ5.9" x 2.2" (Φ149 x 55mm)
• Weight - 1.2 lbs (524g)
• Material - Metal + Plastic
• Working Environment - -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH
• Strorage Environment - -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH
• surge protection - 4kv
• Reset Button - Support
