4890201 Potter FASPKR-W Low Profile Ceiling or Wall Mount Speaker - White

Features

• 24VDC tamperproof selectable candela options of 15, 30, 60,75, and 110
• Speaker voltage 25 or 70.7 VRMs standard, field selectable
• Field selectable power taps: 1/8W, 1/4W, 1/2W, 1W, 2W, 4W
• High quality dBA output (intelligible)
• Frequency range 400-4000 Hz
• Screw Terminals, separate in/out wiring (18-12 gauge)
• Tamperproof grill
• Faceplate available in red or off-white
• Product includes a 5 year warranty

Application

The Potter SPKSTR-24CLP is a ceiling mount, low profile, field adjustable speaker/strobe and the FASPKR is a universal mount speaker designed to meet code requirements for audio, visual, and voice communications. The SPKSTR-24CLP Series are quality speaker products offering dependable evacuation signaling, visual alarms, or a combination of both.

Description

The SPKSTR-24CLP has high output tamperproof candela selections of 15, 30, 75, 95, and 115. The SPKSTR-24CLP and FASPKR provide a 25 or 70.7 VRMs speaker with field selectable power taps of 1/8W, 1/4W, 1/2W, 1W, 2W, or 4W. The SPKSTR-24CLP strobes can be synchronized using the Potter AVSM Synchronization Control Module, FACP, or power supplies that produce a Gentex Synchronization Protocol.

The SPKSTR-24CLP and FASPKR can be mounted to a 4” X 2 1/8” deep back box without an extension ring or Potter SPKRBB surface back box.

The SPKSTR-24CLP and FASPKR are constructed of high textured Plastic.

Architect & Engineering Specifications

TThe fire alarm speaker shall be Potter FASPKR, SPKSTR-24CLP or equivalent. The speaker shall be capable of producing alarm tones or voice on all 25 or 70.7 VRMs audio systems. The speaker shall provide incremental tap settings of 1/8, 1/4, 1/2, 1, 2, or 4 watts. Minimum dBA ratings at 1/4 watt shall be 76.7 dBA and at 4 watts 87.9dBA. Tap settings shall be adjustable with field selectable jumper pins. The speaker shall also have an optional visual signal capability.

The visual signal shall have a 1 Hz flash rate regardless of input voltage. All field wiring connections shall be made via separate in-out terminal connections and the speaker or speaker strobe shall be ANSI/UL, CSFM listed and comply with all local, state and federal fire alarm codes/standards.

Technical Specifications

• Speaker Operating Voltage - 25VRMs or 70.7VRMs
• Strobe Operating Voltage - 16-33VDC
• Synchronization Module - Potter AVSM
• Environmental Limitations - 32°F to 120°F Indoor Only
• Unit Dimensions - 6.1” (15.494cm) square X 1.88” (4.7752cm) deep
• Back Box - 4” X 2 1/8” deep box or Potter SPKRBB surface back box
• Shipping Weight - 1.5 lbs
