H6HRLN20TB Speco Technologies HRLN Series 6 Channel HD-TVI/Analog + 4 Channel IP DVR Up to 120FPS @ 1080p - 20TB

Specifications

• Channels - 6

System

• Compression - Standard H.265
• OS - Embeded Linux

Video

• Analog Video Input - BNC x 4
• Configurable Analog Inputs - 4
• IPC Only Input - 2CH (up to 6-CH) *
• Network Access & Transfer Bandwidth - 16/40Mbps
• Network Access Format - 8MP/5MP/4MP/3MP/1080P/960P/720P@25/30fps
• Output
  • HDMIx1: 4Kx2K/1920x1080/1280x1024
  • VGAx1: 1920x1080/1280/x1024/1024x768
  • BNCx1: CVBS (used as the main or spot output)

Audio

• Input - RCA x 4
• 2-way Audio - Take up channel one audio input
• Local Output - RCAx1

Record

• Record Stream - Dual stream recording
• Resolution - 4K/5MP/4MP/1080P/720P/WD1
• Frame Rate
  • Analog: - 5MP@ 12fps (PAL/NTSC), 4MP/3MP@ 12fps/15FPS (PAL/NTSC), Under 4MP@ 25fps/30fps (PAL/NTSC)
  • IP: - 8MP@ 20fps (PAL/NTSC), Under 8MP@ 25fps/30fps (PAL/NTSC)
• Bit Rate - 32~78Mbps
• Mode - Manual, schedule, motion, sensor, intelligence

IP Input

• Resolution - 8MP/5MP/4MP/3MP/1080P/960P/720P@25fps/30fps

Playback

• Simultaneous Playback - Max 4-CH
• Search Mode - EZ Search, museum search, time search, event search, bookmark search, snapshot search
• Smart Search - Highlighted color to display camera records in a certain period of time, different colors refer to different record events
• Function - Play, pause, FF, FB, etc.

Alarm

• Mode - Manual, sensor, motion, exception, intelligence
• Input - 4-CH local alarm input; Support IPC alarm input
• Output - 1-CH local alarm input; Support IPC alarm input
• Linkage - Record, snapshot, preset, e-mail, pop-up window, etc.

Network

• Interface - RJ45 10M/100Mbps x 1
• Protocol - TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP
• Web Client - Multiple online users monitoring

Mobile Device

• OS - Speco Blue iOS, Android, SecureGuard Client
• Other Viewing Platforms - Apple TV and Amazon Fire TV

Storage

• HDD - SATAx1, max 20TB per HDD
• E-SATA - eSATAx1 max 8TB

Export

• Local - USB, USB mobile HDD
• Network - Yes

Interface

• USB - USB2.0x2
• Remote Control - Yes

Dimensions

• Power Supply - DC12V/4A
• Power Consumption - ≤10W(without HDD)
• Dimensions(WxDxH) - 11.8” x 9.8” x 1.8” (300mm x 248mm x 45mm)
• Working Environment - 14°F to 122°F (-10°C°C to 50°C°C)

H6HRLN20TB Specifications PDF
