066-660/P/YL Vertical Cable 066-660 Series 23 AWG Unshielded Twisted Pair Solid Bare Copper CMP Plenum Cat6 Cable - 1000' Pull Box - Yellow

Search available promotions and discounts for this Item

SKU: 066-660/P/YL

Brand: Vertical Cable

CAT6 UTP CMP Rated â€“ 066 Series (UL-Listed)

CAT6, 23 AWG, UTP, 8C Solid Bare Copper, 550MHz, CMP Rated.

Features

High-Performance Data Cable
Suitable for High-Speed Data Applications, Gigabit Ethernet, Fast Ethernet
Easily Identified Color-Striped Pairs
Unshielded Twisted Pair (UTP) Cable
23AWG Solid Bare Copper Conductors
Exceeds ANSI/TIA 568-C.2
Supports PoE+ (Type 2) IEEE 802.3at (25.5W)
Excellent Attenuation and Crosstalk
UL listed, RoHS Compliant, TAA Compliant
1000 ft Pull Box
Color : Black, Blue, Green, Orange, Purple, Red, White, Yellow

More details...

Search available promotions and discounts for this Item

MPN: 066-660/P/YL

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Part Number - 066-660/P/YL

Technical Data

NVP - 69%

Insulation

Insulation - FEP
Thickness: - 0.009 in. (0.22 mm)

Jacket

Jacket - FR-PVC
Outer Diameter - 0.21 in. (5.3 mm)
Separator (Divider) - No (Spline-less)
Rip Cord - Yes

Color of Paris

Pair 1: - Blue, White-Blue
Pair 2 - Orange, White-Orange
Pair 3 - Green, White-Green
Pair 4 - Brown, White-Brown

Electrical Characteristics

Standard - ANSI/TIA-568.2-D
Impedance: - 100Î©Â±15%

Standards

Flame Test 6 (FT6 Rating), ANSI/NFPA Standard 262 with the applicable electrical transmission characteristics

Jacket Printing

Vertical Cable E191267 (UL) c(UL) CMP FT6 75 ÂºC 23 AWG 4PR - ETL VERIFIED CAT6 ANSI/TIA 568.2-D TESTED TO 550MHz ROHS COMPLIANT P13199 1000FT 01/2023

Electrical Characteristics

Conductor Resist.: - 93.8 Î©/km 20Âº C Max
Mutual Capacitance: - 5.6 nF/100m Max
Resist. Unbalance: - 5% Max
Compac. Unbalance: - 330 pF/100m Max
Jacket color available in Black, Blue, Green, Gray, Red, White, Yellow, Orange, Purple, Pink

066-660/P/YL Specifications PDF
