065-302/A/P/GR Vertical Cable 23 AWG 4 Unshielded Twisted Pair Solid Bare Copper CMP Plenum Cat6A Cable - 1000' Spool - Green

Search available promotions and discounts for this Item

SKU: 065-302/A/P/GR

Brand: Vertical Cable

Category-6A (Augmented) (UTP) Cable
23AWG Solid Bare Copper Conductors
High-Performance Data Cable
Suitable for 10GS High-Speed Applications
For Plenum Spaces (CMP rated)
Exceeds ANSI TIA/EIA 568C.2
UL Listed, RoHS Compliant
TAA COMLIANT
Supplied in 1000´ Wooden Spool
Color : Green

More details...

Search available promotions and discounts for this Item

MPN: 065-302/A/P/GR
Ordering Notes: Service Professionals Only

MSRP Price: $926.00

Online Price: $926.00

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Technical Data

Rated Temperature (°C) - 75
Rated Voltage (V) - 30v
Product Standard Certification - CMP (Plenum)
NVP - 69%

Conductor

Material - Solid Bare Copper
Size - 23 AWG
Insulation - FEP
Separator - Yes

Jacket

Material - FRPVC
Outer Diameter (±0.10) - 6.6 mm
Rip Cord - Yes

Color of Pairs

Pair 1 - Blue, White-Blue
Pair 2 - Orange, White-Orange
Pair 3 - Green, White-Green
Pair 4 - Brown, White-Brown

Product Certifications

NEC Article 800, ANSI/TIA/EIA 568C.2 Category 6A, 11801:2002 Category 6A, UL 910:CMP Rating, RoHS Compliant
Supports all CAT6A applications including
Ethernet 10 Gigabit, 100BASETX, 100BaseVG ANYLAN, 155ATM, 622ATM, NTSC/PAL Component or Composite Video, AES/EBU Digital Audio, AES51, RS-422

Marking on Jacket

Marking - Vertical Cable E191267 (UL)c(UL) CMP FT6 75C 23 AWG 4PR - Cat6A ANSI/TIA 568-C.2 ROHS Compliant XXXXFT (Sequential Foot Markers)

Electrical Properties

Max. Mutual Capacitance - 5.6nF/100m
Max. Resistance Unbalance - 5%
Max. Capacitance Inbalance - 330 pF/100m
Max. D.C. Resistance - 9.38 Ω/100m

065-302/A/P/GR Specifications PDF
