PAR-P4PTZXIR2812NH-AIWL InVid Tech Paramont Series 2.8-12mm Motorized 25x Optical Zoom 30FPS @ 4MP Outdoor White Light Day/Night WDR PTZ IP Security Camera 12VDC/PoE

Specifications

Camera Module

• Image sensor - 1/2.7″ progressive scan CMOS with BSI and NIR+ technology
• Mini. Illumination - Color: 0.01 Lux @ (F1.6, AGC ON); B/W: 0.002Lux @(F1.6, AGC ON);0Lux with IR
• Image setting - Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, and AWB adjusted by client
• Shutter Speed - 50Hz: 1/25s~1/25,000s, 60Hz: 1/30s~1/30,000s
• White Balance - Auto/Manual/Indoor/Outdoor
• Gain - Auto/Manual
• Day & Night - Auto/Manual
• Aperture control - N/A
• S/N Ratio - ≥52dB
• 3D DNR - Auto/Manual
• AE Enhancement - BLC, HLC, WDR
• Privacy Mask - 4 Programmable privacy masks, up to 8 per request
• Picture overlay - Logo picture could be overlaid on video with 128x128pixels,24bits BMP format
• Font overlay - Max 15characters per line, 8lines max, white color or red color

Lens

• Focus length - f=2.8-12mm lens,4x optical
• Zoom Speed - About 1.6second(Wide->tele)
• Field of View - Horizontal: 97° to 31°±5%;Vertical: 51° to 18°±5%; Diagonal: 115° to 36°±5% (wide-tele)
• Working distance - wide: 0.3m ~ INF; tele: 0.5m ~ INF
• Aperture Range - F1.6~ F2.7 (wide-tele)
• IRCut filter - Electrical switchable ICR
• DORI table
  • Lens - 2.8mm - 12mm
  • Detect(25px/m) - 223 ft (68m) - 678.1 ft (206.7m)
  • Observe(63px/m) - 88.9 ft (27.1m) - 269 ft (82m)
  • Recognize(125px/m) - 44.6 ft (13.6m) - 135.5 ft (41.3m)
  • Identify(250px/m) - 22.3 ft (6.8m) - 68 ft (20.7m)M

PTZ

• Pan Range - 0~355°
• Pan speed - Configurable, from 0.1~80°/s; Preset speed: 80°/s
• Tilt Range - From -5° to 90°
• Tilt Speed - Configurable, from 0.1°~ 60°/s, Preset speed: 60°/s

Pan/Tilt action

• intervals - At least 10seconds, adjustable
• Proportional Zoom - Yes
• Preset - 300
• Cruise - 8 cruises, up to 16 presets for each cruises
• Trace - 4 traces, record time over 3 minutes for each trace
• Power off memory - Support
• Action mode - Preset/Cruise/Trace/Auto Scan/Random Scan
• 3D Positioning - Support
• PTZ Position Display - Support
• Schedule Task - Preset/Cruise/Trace/Random Scan/Boundary Scanning /Dome reboot

Supplement Light

• IR Distance - Up to 164 ft (50m),4pcs of IR Array into 2 Groups, auto switch with zoom ratio
• Smart IR - Yes
• White light Distance - Up to 98ft , 2pcs of White LED Array (Deterrent Only)
• White light Mode - Flash mode(2x brightness), time interval adjustable; Constant Mode ( On AI Events)

Network

• Max Resolution - 2560x1440
• Main stream - 25fps (2560x1440, 2048x1536, 1920x1080, 1280x960, 1280x720); 30fps (2560x1440, 2048x1536, 1920x 1080, 1280x 960, 1280x 720)
• Sub stream - 25fps (704 x 576, 640 x 480, 352 x 288); 30fps (704 x 480, 640 x 480, 352 x 240)
• Third Stream - 25fps (1280 x 720, 704 x 576, 640 x 480, 352 x 288) ; 30fps (1280 x 720, 704 x 480, 640 x 480, 352 x 240)
• Video compression - Smart H.265+/H.265/H.264+/H.264/MJPEG
• H.264 Encoder - H.264/AVC codec BP/MP/HP, level 5.1
• H.265 Encoder - H.265/HEVC codec MP, level 5.0
• Video bit rate - 64Kbps ~ 16Mbps
• Audio Compression - G.711 A/U
• Audio bit rate - 64Kbps
• Protocols - HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP,DHCP, PPPoE
• User / Host - Up to 16 users, 3 levels: Administrator, Advanced User and Normal User
• Security Measures - User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering

Smart Features

• Basic event - Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, SD full, SD error)
• Face recognize - Support human face detection, max 15 human faces per scene. Support face capture, tracking, comparison, edge storage
• Road traffic - Vehicle detecting and tracking, etc
• Smart Detection - Tripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exiting detection,etc. ( Human and Vehicle Classification)
• Smart Tracking - Smart tracking of human or vehicle, auto/manual
• Active Deterrence - Flash strong white light and predefined voice upon invaders detected. Support 10 more different predefined voice clips
• Dual way talk - Alarm Deterrent + Two Way Audio

System Integration

• Ext. Audio Interface - 1-ch audio input(mic in),2.0-2.4Vp-p,1kΩ±10%;1-ch audio output(line out),line level, impendance:600 Ω
• Built-in speaker - 4Ω, 2.5Watt. Rotation with camera lens direction, up to 15 ft distance audible
• Built-in MIC - 1channel, rotation with camera lens direction, up to 15 ft distance voice recordable
• Audio device switch - Default use built-in speaker and MIC, manually switch to external
• Alarm Linkage - Alarm actions, such as Preset, Cruise, Trace, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card, Send Email,etc
• Network Interface - 1 RJ45 10M/100M Adaptive Ethernet (Support PoE+ )
• Storage Slot - Standalone ext. memory card chamber, support microSD/TF card, up to 256GB
• Serial interface - N/A (RS485/232)
• Auxiliary video out - N/A(BNC/CVBS/TVI)
• Reset button - Yes
• Heat and Fan - Built-in temperature sensor, auto shut down at over- temperature; auto heat at cold start. No built-in fan
• Water removal - Dust and Water-resistant coating for lens cover
• API - ONVIF, support TVT SDK and third-party management platform
• Client - Paramont NVR, Paramont CMS; free iOS and Android App
• Web Browser - IE8-11
• App version - Default:5.0.1. Update to 5.1.1 per request
• Audio Sensitivity - -36db

General

• Languages - Czech; English, German; Hungarian ; Italian ; Japanese ; Korean ; Portuguese, Polish;Russian, Romanian, Spanish; Spanish(Mexico);Simplified Chinese; Turkish; Traditional Chinese. etc
• Power - DC12V±20%,3000mA,PoE+ (802.3.at), AVG. 4.5Watt, Max 16.2Watt at day; 20.2Watt at night (LED on, Speaker on + PT Rotation)
• Working condition - -40°F ~ 158°F (-40°C ~ 70°C) IR off, -40°F ~ 140°F (-40°C ~ 60°C) IR on; Cold start≥- 25°C(1Hour waiting), ≤90%RH
• Storage condition - -40°F ~ 158°F (-40°C ~ 70°C) ; ≤ 95% RH
• Protection - 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
• Shield Material - Main body: Aluminum Alloy(ADC12),Decoration: Polymer(Glass fiber and Plastic)
• Dimensions - 5.1 x 6.4′ (130 x 162 mm)
• Net Weight - Approx. 2.65lb (1.2Kg)
• Certification - IP66,IK10 (include lens window), ROHS,CE,FC,3C
