SKY-SU301-0 Hanwha Vision Wisenet SKY Bridge 301 1U Rack Bridge

Specifications

System

• Maximum Cameras @ 1MP - 15 / 30 / 50
• Maximum Cameras @ 4MP - 12 / 25 / 35
• Maximum Cloud Analytics - 5 / 10 / 10
• Hard Disk Drive Network ports - 1TB, 800Gb usable for video storage, spinning hard disk
• Video output - Dual gigabit ethernet RJ-45, 1x VGA, 1x DVI / 1x VGA, 1x HDMI, 1x DisplayPort (401 / 501)
• Indicator Lights - Power, Disk activity
• USB ports - 2x USB 3.0
• Operating System - Embedded Linux
• Included accessories - Power cord, rack mount brackets
• Rack Mount Brackets - Included
• Ordering SKU - EN-SU301-0 / EN-SU401-0 / EN-SU501-0

Mechanical

• Form Factor: - Rack mount or shelf / tabletop mount
• Color/Material - Black/Metal
• Dimensions - 1U 16.81" x 9.88" x 1.75" (427mm x 251mm x 45mm)
• Weight: - 7.64lb (3.47kg) / 8.62lb (3.91kg) / 8.6lb (3.9kg)

Electrical

• Power Supply: - Internal, 65 W / 50 W / 120 W
• Power Input - 100 - 240 VAC

Environmental

• Operating Temperature: - 32°F to 95°F (0°C to 35°C)
• Operating Humidity: - 0% to 70% RH, non-condensing
• Certifications - FCC, UL, PSE, CE, CCC(S&E), REACH, RoHS, C-Tick, NDAA
