VIS-C5TXIRA28WL InVid Tech Vision Series 2.8mm 25FPS @ 5MP Outdoor White Light Day/Night DWDR Turret HD-TVI/HD-CVI/AHD/Analog Security Camera 12VDC

Specifications

Sensor

• Pixel - 5MP
• Size - 1/2.7"
• Minimum illumination - 0.005lux (F1.4, AGC ON) 0 lux (white light on)

Lens

• Lens - 2.8mm
• Lens mount - M12
• Angle of view - H: 111.5° V: 58.9° D: 134.8°

Illuminator

• Illuminator - Two white-light illuminators
• Illumination distance - 131’ (40m)
• Lifetime - ≥60,000 hours

Video

• Resolution
  • 5MP@25fps: 2880(H)×1620(V); 5MP@20fps: 2592(H)×1944(V); 5MP@12.5fps: 2592(H)×1944(V)
  • 4MP: 2560(H)x1440(V)
  • 1080P: 1920(H)x1080(V)
• Frame rate
  • TVI: 5MP@20fps (default), 5MP@12.5fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
  • AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
  • CVI: 5MP@25fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
  • CVBS: PAL, NTSC
• Shutter time - PAL: 1/25s-1/50000s NTSC: 1/30s–1/50000s


• Exposure mode - Four modes: Global (default), BLC, HLC, DWDR
• Day/Night - 24/7 color images
• Digital noise reduction - 2D
• White balance - Two modes: Auto (default), Manual
• WDR - DWDR
• Flip - Supports 180° horizontal flip, 180° vertical flip

Audio

• Microphone - Built-in Mic, Audio Over Coax (AoC) Camera audio
  • TVI: 5MP@20fps, 5MP@12.5fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
  • CVI: 5MP@25fps, 4MP@30fps, 4MP@25fps

Interface

• Power - 5.5mm power interface
• Video output - BNC, supports TVI/AHD/CVI/CVBS
• Audio Sensitivity - -32±3dB

Operating environment

• Temperature - -22°F ~ 140°F (-30°C ~ 60°C)
• Humidity - ≤95% (RH, non-condensing)
• Surge protection - 4kV
• Ingress protection - IP67

General

• Power - DC12V (±25%), with reverse polarity protection and surge protection. Max 3.28W
• Mount - Surface mount (default), optional junction box and wall mount bracket
• Dimensions - Φ 4.4 x 3.8 in (Φ111mm*96mm)
• Material - Metal and plastic
• Weight - 0.79lb (356g)
• Certification - CB, CE, FCC, UL

VIS-C5TXIRA28WL Specifications PDF
