[DISCONTINUED] ST2000VX015 Seagate SkyHawk Surveillance Grade Hard Drive 6Gb/s 256MB Cache 3.5" SMR Air - 2TB

Specifications

• Standard Model Numbers - ST2000VX015
• Interface - SATA 6Gb/s
• Recording Technology - SMR
• Drive Design - Air

Features and Performance

• Drive Bays Supported - Up to 8
• Cameras Supported - Up to 64
• Max Sustained Transfer Rate OD (MB/s) - 180MB/s
• Cache (MB) - 256

Reliability/Data Integrity

• Tarnish Resistant - Yes
• Nonrecoverable Read Errors Rate, Max - 1 per 10E14
• Power-On Hours per year - 8760
• Workload Rate Limit (WRL) - 180
• Mean Time Between Failures (MTBF) (hours) - 1,000,000hr
• Warranty, Limited (years) - 3
• Rescue Data Recovery Services (years) - 3

Power Management

• Startup Current, Typical (12V, A) - 1.8
• Average Operating Power (W) - 3.7W
• Idle Average (W) - 2.5W
• Standby Mode/Sleep Mode, Typical (W) - 0.25/0.25
• Voltage Tolerance (5V) - ±5%
• Voltage Tolerance (12V) - ±10%

Environmental/Temperature

• Operating (ambient, min °F) - 32
• Operating (drive reported, max °F) - 158
• Nonoperating (ambient, min °F) - -40

Physical

• Height (in, max) - 1.028 in
• Width (in, max) - 4.01 in
• Depth (in, max) - 5.787 in
• Weight (lb, typical) - 1.345 lb

ST2000VX015 Specifications PDF
