JP-DVF-PR Aiphone Flush Mount Video Door Station with Proximity Card Reader

The JP-DVF-PR is a vandal-resistant door station for the JP Series with a built-in AC-PROX-1G proximity card reader. The door station can either be surface or flush mounted. The intercom portion of the JP-DVF-PR connects to a JP-4MED master station with a 2-conductor, 18-AWG wire, and the reader connects to an access control system with a standard Wiegand connection.

Specifications

Door Station

• Power Source - 24V DC (supplied from JP‑4MED master station)
• Communication - Open voice hands-free
• Camera - 1/4" color CMOS
• Min. Illumination - 5 lux
• Wiring - 18-gauge 2-conductor
• Wiring Distance - 330'
• Operation Temp - -4°~140°F (-20°~60°C)
• Dimensions - 11-11/16" H x 7" W x 2-1/16" D

Card Reader

• Power Input - 5~14V DC
• Power Draw - 45mA
• Frequency - 125kHz
• Certifications - CSA, FCC, CE, C-Tick
