VS-1000E Takex Vape & smoke particle sensor

SKU: VS-1000E
Brand: Takex

VS-1000E

Features

  • Adjustable detection sensitivity (Standard/Low)
  • Selectable alarm contact output (NC/NO)
  • Built-in sounder and alarm LED
  • Tamper-resistant cover locking mechanism
  • Suitable for ceiling or wall mounting

Introducing VS-1000E, a cutting edge Vape & Smoking Sensor designed to address the growing concern of vaping and smoking in schools, restrooms, and similar environments. VS-1000E leverages a high-sensitivity particle detection system coupled with advanced algorithms to adapt to changing environmental conditions, ensuring rapid and reliable identification of vaping and smoking activities. Unlike many vape sensors, the VS-1000E operates independently without the need for app-based management, offering seamless, license-free operation.

  • Adjustable Detection Sensitivity: Offers standard and low sensitivity settings to accommodate various application needs.
  • BuConfigurable Alarm Output:llet Allows selection between normally closed (NC) and normally open (NO) relay outputs, providing flexibility in integration with existing alarm systems.
  • Integrated Audio-Visual Alerts: Equipped with a built-in sounder and LED indicator to provide immediate local notifications upon detection.
  • Tamper-Resistant Design: Features a secure cover locking mechanism to prevent unauthorised access or tampering.
  • Versatile Mounting Options: Suitable for both ceiling and wall installations, ensuring seamless integration into any environment.
  • Self-Diagnosis Functionality: Continuously monitors its own operation and triggers an alarm output and LED indication in case of voltage abnormalities or module failures.
  • Simple Installation: Engineered for rapid deployment with an innovative twist-lock base and tool-less, push-fit terminals, enabling effortless installation in seconds.li>

More details...
MPN: VS-1000E
MSRP Price: $349.00
Web Price$349.00
Add to List
DWG Dealer Program Become a DWG Dealer to see your pricing. Dealer pricing, quoting, volume discounts, and sales support on thousands of products.


Product Details

VAPE SENSOR

Designed to combat the growing problem of teenage vaping on school grounds and other similar environments

HIGH SENSITIVITY PARTICLE SENSOR

VS-1000E detects vaping and smoking by airborne particles.

VERSATILE USE

The dry contact relay (N.C./N.O. selectable) simplifies connection to existing alarm systems.

INTEGRATED ALARM BUZZER

The built-in buzzer provides immediate local notification of detected vaping or smoking

DISCREET DESIGN

The unobtrusive design blends seamlessly into any environment.

FALSE ALARM IMMUNITY

Advanced detection algorithms adapt to changes in the surrounding environment, significantly reducing the occurrence of false alarms.

CONFIGURABLE ALARM OUTPUT

Choose between one shot (approx. 2sec.) or Real-time output modes depending on your specific application needs

SELF-DIAGNOSIS

The sensor automatically monitors its own operation and triggers an alarm output and LED indication in the case of voltage abnormality or module failure.

Specifications

  • Supply voltage - 10.5V to 28V DC (non-polarity)
  • Current consumption - 85mA max.
  • Alarm output - Contact : Solid state relay (N.C./N.O. selectable) Operation : One shot
    (approx. 2sec.) / Detecting time Capacity : 30V (AC/DC) 0.2A (resistive load)
  • Tamper output - Contact : Dry contact relay (N.C.)
    Operation : Activated when cover is detached (Continuous output)
    Capacity : 30V (AC/DC) 0.1A (resistive load)
  • LED indicator - Warm-up : Blinking
    Detection : Lights on (LED ON/OFF selectable) Error : Fast blinking
  • Buzzer - Sound at detecting (disable / 10sec. / 30sec. / continuous)
  • Wiring - Screwless terminal
  • Mounting position - Indoor (Ceiling / Wall)
  • Weight - 210g (7.4oz)
  • Appearance - Resin (Body: White / Base: Black)
  • Ambient temperature - 0°C to +50°C (+32°F to +122°F)
    without condensation/frozen
