2-N-1PROXHAF Linear 2-N-1 Dual-Mount Proximity Reader

Search available promotions and discounts for this Item

SKU: 2-N-1ProxHAF

Brand: Linear

Model Number: 2-N-1ProxHAF
Part Number: 620-100451
Designed to fulfill two different mounting requirements without needing any additional hardware
Can be installed as either a mullion-mount reader or, when paired with the provided adapter plate, turns the reader into a single-gang electrical box style reader
Low profile for both mullion and single-gang installations
Ready to install right out of the box for either configuration

More details...

Search available promotions and discounts for this Item

MPN: 2-N-1ProxHAF

MSRP Price: $169.32

Online Price: $122.40

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Mfg Ordering Part # - 620-100451
Reader Type - Proximity; 26- to 37-bit Wiegand
Frequency - 125 kHz
Mounting - Mullion or Single Gang
Dimensions (H x W x D) - Single-Gang: 4.77" x 2.96" x 1.33" (121.1 x 75.1 x 33.7 mm), Mullion: 3.92" x 1.74" x 0.98" (99.5 x 44.2 x 24.9 mm)
Weight -3 oz. (85g)
IP Code - IP67
Voltage - +5 to +16 VDC
Current Draw - 30 mA typical, 75 mA peak @ 12VDC
Read Range - Up to 6 inches (152 mm)
Cabling - 24 AWG minimum, multi-conductor stranded with an overall foil shield 500'
Interface - Wiegand ABA Track II
Operating Temperature - -40° F to 149° F, (-40° C to +65° C)
Color - Black
Audio Tone - Sounder included
Indoor & Outdoor Installation - Electronics sealed in weather and tamper-resistant epoxy potting
Warranty - Limited lifetime warranty
LED - Four-state indicator (red, green, amber, off)
Certification - ETL listed to UL294, FCC, ICC, CE, C-Tick
Designed for these credentials - HID 125 kHz Proximity protocols, AWID 125 kHz Proximity protocols, Farpointe Data Pyramid Series Proximity Cards and Tags

2-N-1ProxHAF Specifications PDF
