VAR-VLK-i4-2-C Raytec VARIO Covert 2 x 940nm Lighthouse Kit

VARIO Lighthouse Kit (VLK) is a fully integrated lighting and housing solution designed for easy camera integration, quick and easy mounting with the ability to mount up to two IP or analogue cameras.

VLK provides two integrated VARIO LED illuminators, available in Infra-Red, White-Light or Hybrid. Lighting and cameras can be used together for a variety of applications including CCTV, ANPR/LPR and thermal. The VLK Control Interface delivers the highest level of flexibility and control for meeting exact operational requirements for outstanding 24/7 performance. Lighting can be easily configured for activation via photocell or on demand via camera or external input (e.g. on detection of motion). Lighting on demand delivers real savings through reduced electrical consumption and when using White-Light provides a powerful, visible deterrent. The integrated photocell can be used to trigger switching of camera day/night mode in conjunction with the illuminators

Specifications

VLK Unit (lighting and housing)

• Input - 15-24V AC/DCTotal VLK Consumption
  • 59W
  • 2 illuminators 48W
  • camera 6W (typical)
  • camera heater 5W
• Weight - 4.6kg (10lbs) including wires and bracket
• Dimensions (LxWxH) - 336 x 302 x 173mm (13.2 x 11.9 x 6.8") (excluding bracket)
• Internal Camera Space Dimensions - See Page 2 Diagram
• Drilling Dimensions - 4 x M5 holes 40x62mm (1.57 x 2.44")
• Cable - Cat5e 8 x 24AWG and Power/Aux 6-core
• Cable Length - 4m(13ft)
• Colour - Black
• Environmental - IP66
• Temp Range - -50 to +50°C (58°F to 122°F)
• Illumination Angle
  • Standard pack includes 10 circular +35 x 10 (fitted as standard and 60 x 25 elliptical lenses
  • Additional optional lenses - 80 x 30 and 120 x 50
• Optics - SMT LED's
• Wavelength - 850nm or 940nm or White-Light (Hybrid options available)

Bracketry

• Integrated cable managed wall bracket provided as standard.Fully pre-wired.
• Optional pole mount and wall mount brackets available – contact Raytec

Integrated Command and Control Technology

• Integrated Standard Features
  • In-built photocell for automatic on/off operation
  • LED status indicator provides status on performance of the unit
  • Photocell following output
• Integrated Advanced Features
  • Power adjust from 20-100%
  • Photocell sensitivity adjust
  • Timer function (up to 30 mins)
  • Telemetry control
  • Remote Dimming
  • LED status indicator on/off
  • Restore factory default settings

VAR-VLK-i4-2-C Specifications PDF
