[DISCONTINUED] GV-LPC2210 Geovision Motorized Varifocal 30FPS @ 1920 x 1080 Outdoor IR LPR IP Security Camera 24VAC/48VDC/PoE++

Specifications

Camera

• Image Sensor - 1/2.8" progressive scan super low lox CMOS
• Picture Elements - 1920 (H) x 1080 (V)
• Camera Type - Color, B/W
• Shutter Speed - Auto / Manual (1/120 ~ 1/2000 sec)
• White Balance - Auto / Manual (2800K ~ 8500K)
• S/N Ratio - 52 dB
• Max. Speed - 120 km/h (75 mph)

Lens

• Megapixel - 2 MP
• Lens Type - Motorized varifocal lens
• Focal Length - 9 ~ 22 mm
• Maximum Aperture - F/1.2
• Image Format - 1/2.7"
• Horizontal FOV - 38° ~ 18°
• Operation - Focus: Auto, Zoom: 2.5x optical zoom, Iris: P‐Iris
• IR LED Quantity - 4 high power IR LEDs
• IR Distance - 10 ~ 20 m (32.8 ~ 65.6 ft)

Operation

• Video Compression - H.264, MJPEG
• Video Stream - Dual streams from H.264 and MJPEG
• Frame Rate - 30 fps at 1920 x 1080 * The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes)
• Image Setting - Brightness, Contrast, Saturation, Sharpness, Gamma, Auto Exposure, White Balance, Flicker less, Image Orientation, Shutter Speed, Maximum Video Gain, D/N Sensitivity, Denoise, Defog, Metering
• Audio Compression - G.711, AAC (Optional)
• Audio Support - Two‐way audio

Video Resolution

• Main Stream - 4:3 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240, 16:9 1920 x 1080, 1280 x 720, 640 x 360, 448 x 252, 5:4 1280 x 1024, 640 x 512, 320 x 256
• Sub Stream - 4:3 640 x 480, 320 x 240, 16:9 640 x 360, 448 x 252, 5:4 640 x 512, 320 x 256
• TV‐Out - NTSC, PAL (640 x 480 resolution)

Network

• Interface - 10/100 Base‐T Ethernet, RJ‐45 connector
• Protocol - HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP), ONVIF (Profile S)

Mechanical

• Temperature Detector - Yes
• Camera Adjustment - Pan 0° ~ 270°, Tilt 0° ~ 70°
• Power - DC 48V, AC 24V (optional), High PoE (PoE++, 120 W)
• Ethernet - RJ‐45
• Audio - 1 In (microphone jack, 3.5 mm / 0.14") 1 Out (stereo phone jack, 3.5 mm / 0.14")
• Digital I/O - 1 In / 1 Out
• TV‐Out - BNC connector (640 x 480 resolution)
• LED Indicator - N/A

General

• Operating Temperature - ‐40°C ~ 50°C (‐40°F ~ 122°F)
• Humidity - 10% ~ 90% (non‐condensing)
• Power Source - DC 48V, 2.5A, AC 24V 3A (Optional), High PoE (PoE++, 120 W) * If you require AC 24V 3A for optional operation, please specify upon ordering for the correct value of capacitance to be placed in the camera.
• Max. Power Consumption - 50 W
• Dimensions Without support rack - 406 x 145 x 109 mm (16" x 5.7" x 4.3")
• Cable Length - 1 m (3.28 ft)
• Weight - With support rack 3.32 kg (7.32 lb), Without support rack 2.62 kg (5.78 lb)
• Ingress Protection - IP67
• Vandal Resistance - IK10 for metal casing
• Heater On - ‐40°F ~ 46.4°F
• Fan - Constantly On
• Regulatory - CE, FCC, RCM, RoHS compliant

Power over Ethernet

• PoE standard - High Power Over Ethernet (PoE ++) / PD
• PoE Power Supply Type - Mid‐Span
• PoE Power Output - DC 48V, 2.5A (120 W Max.)

Web Interface

• Installation & Management - Web‐based configuration
• Firmware Upgrade - Remote upgrade through Web Browser GV‐IP Device Utility included in the Software DVD
• Access from Web Browser - Live View, Video Quality, Bandwidth Control, Image Snapshot, Audio, Picture in Picture, Picture and Picture, Text Overlay
• Language - Arabic / Bulgarian / Czech / Danish / Dutch / English / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian / Japanese / Lithuanian / Norwegian / Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish

Applications

• Network Storage - GV‐System (GV‐DVR/NVR), GV‐VMS, GV‐Recording Server
• Smart Device Access - GV‐Eye for Android and iOS Embedded 3GPP/ISMA browser
• Live Viewing - IE, GV‐Edge Recording Manager
• CMS Server support - GV‐Control Center, GV‐Center V2, GV‐Vital Sign Monitor
• LPR Management - GV‐ASManager

GV-LPC2210 Specifications PDF
