[DISCONTINUED] GV-PPTZ7300 Geovision 2-in-1 30FPS @ 1920 x 1080 Outdoor Day/Night PTZ IP Security Camera with Integrated 10FPS @ 2560 x 1920 Outdoor Day/Night WDR Fisheye IP Security Camera 56VDC/PoE++

Introduction Video

Specifications

System Requirements

• OS - 64‐bit Windows 7 / 8 / 8.1 / 10 / Server 2008 R2 / Server 2012 R2
• GV‐VMS Version - GV‐VMS V15.10.1.0 with patch or later
• Browser - Internet Explorer 7.x or later, Firefox, Google Chrome, Safari

Camera

• Image Sensor - FE: 1/2.5" progressive scan CMOS SD: 1/2.86" progressive scan CMOS
• Picture Elements - FE: 2560 (H) x 1920 (V) SD: 1920 (H) x 1080 (V)
• Minimum Illumination - Color: 0.15 Lux, B/W: 0.10 Lux
• Shutter Speed - FE: Automatic, Manual (1/5 ~ 1/8000 sec.) SD: Automatic, Manual (1/6 ~ 1/60000 sec.)
• White Balance - Automatic, Manual (2800K ~ 8500K)
• Gain Control - FE: Automatic SD: Automatic, Manual
• S/N Ratio - FE: 45 dB SD: 50 dB (AGC Off)
• WDR - FE: Yes (WDR) SD: Yes (WDR Pro)

Optics Lens

• Megapixel - Yes
• Day/Night - Yes (with removable IR‐cut filter)
• Lens Type - FE: Fixed SD: 10x Zoom Lens
• Focal Length - FE: 1.32 mm SD: 5.1 ~ 51 mm
• Maximum Aperture - FE: F/2.0 SD: F/1.6
• Horizontal FOV - FE: 180° SD: 54° ~ 4.9°
• Operation - Focus FE: Fixed SD: Auto / Manual, Zoom FE: Fixed SD: 10x, Iris FE: Fixed SD: Auto / Manual

Operation

• Video Compression - H.264, MJPEG
• Video Streaming - Dual streams from H.264 or MJPEG
• Frame Rate - FE: 10 fps at 2560 x 1920, 15 fps at 2048 x 1944, 1440 x 1376, 1280 x 1200 SD: 30 fps at 1920 x 1080, 60 fps at 1280 x 720, 640 x 360, 448 x 252 *The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes).
• Image Setting - Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker‐less, Shutter Speed, D/N, Denoise, WDR, Defog, Metering
• Audio Compression - G.711, AAC (optional)
• Audio Support - Two‐Way Audio
• Sensor Input - 4 Input (Dry Contact)
• Alarm Output - 1 Digital Output (200 mA 5V DC)

Video Resolution

• Main Stream (FE) - 4:3 2560 x 1920, 20:19 2048 x 1944, 1440 x 1376, 1280 x 1200
• Sub Stream (FE) - 4:3 640 x 480, 20:19 640 x 6
• Main Stream (SD) - 16:9 1920 x 1080, 1280 x 720, 640 x 360, 448 x 252
• Sub Stream (SD) - 16:9 640 x 360, 448 x 252

Network

• Interface - 10/100 Ethernet
• Protocol - DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF (Profile S), RTSP, SMTP, TCP, UDP, 3GPP/ISMA

Mechanical

• Temperature Detector - Yes
• Connectors - Power DC Jack, PoE++, Ethernet Ethernet (10/100 Base‐T), RJ‐45 Connector, Audio 1 in (RCA female for microphone); 1 out (RCA female for speaker), Digital I/O I/O wires, Local Storage 2 micro SD card slots (SD/SDHC, SD version 2.0 only, Class 10)

PTZ Control Panel

• Pan Travel - 355°
• Tilt Travel - -15° ~ 195°
• Manual Speed - 0.5° ~ 460°/s
• Calibration - Auto / Manual
• Presets - Max. Number 255, Accuracy 0.2°
• Sequence - Max. Number 8, Max. Presets 16
• Auto Pan - 8
• Cruise - 4
• Tour - Max. Number 8, Max. Number of Preset / Sequence / Auto Pan / Cruise 16
• Privacy Mask - 8
• Proportional Pan & Tilt - Auto (Pan and tilt speed proportional to zoom ratio)
• Automatic Function - Preset, Sequence, Auto Pan, Cruise, Tour
• Digital Slow Shutter - On / Off
• Motion Detection - On / Off
• Wide Dynamic Range - On / Off
• Day/Night: Mechanical IR Cut Filter - On / Off
• Picture Flip - On / Off
• Image Freeze - On / Off
• Digital Noise Reduction - On / Off
• Alarm - Input 4, Output 1, Reaction Preset, Sequence, Auto Pan, Cruise, Tour

General

• Operating Temperature - -40°F ~ 122°F
• Heater - Heater 1 On: 5°C (41°F); Off: 8°C (46.4°F) Heater 2 On: -7°C (19.4°F); Off: -2°C (28.4°F)
• Fan On - 113°F
• Humidity - 20% to 90% (no condensation)
• Power Source - DC 24V / AC 24V / High PoE (PoE++, 40 W)
• Max. Power Consumption - 40 W
• Dimension (Straight Tube Mount) - 8.332" x 10.709"
• Weight - 8.27 lb
• Ingress Protection - IP67
• Vandal Resistance - IK10 for metal and polycarbonate casing
• Regulatory - CE, FCC, RCM, RoHS compliant

Power over Ethernet

• PoE Standard - PoE++ (40 W) / PD
• PoE Power Supply Type - End‐Span
• PoE Power Output - Per Port 56V DC, 1050 mA. Max. 40 watts

Web Interface

• Installation Management - Web‐based configuration
• Maintenance - Firmware upgrade through Web Browser or Utility
• Access from Web Browser - Camera Live View, Video Recording, PTZ Control, Preset, Sequence, Cruise, Auto Pan, Tour, Change Video Quality, Bandwidth Control, Image Snapshot, Digital I/O Control, Two‐Way Audio, Picture in Picture, Picture and Picture, Motion Detection, Privacy Mask, Visual Automation, Tampering Alarm, Wide Angle Lens Dewarping, Text Overlay
• Language - Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian / Japanese / Lithuanian / Norwegian / Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish

Applications

• Network Storage - GV‐Backup Center, GV‐Recording Server, GV‐VMS * GV‐Backup Center and GV‐Recording Server will be supported in the near future
• Live Viewing - Browser (IE, Chrome, Firefox, Safari)
• CMS Server Support - GV‐Control Center, GV‐Center V2, GV‐Vital Sign Monitor *Integrated live view not supported
