[DISCONTINUED] SD9361-EHL Vivotek 4.7-94mm 60FPS @ 1920 x 1080 Outdoor Day/Night WDR PTZ IP Security Camera 24VAC/PoE - Extreme Weather

VIVOTEK's SD9361-EHL is a high performance H.265 Full HD speed dome network camera. Armed with a 20x optical zoom lens, the camera is able to capture fine details at top-notch quality. By combining both H.265 and VIVOTEK's Smart Stream II technology which enables the camera to optimize quality for desired regions and therefore to maximize efficiency of bandwidth usage, it is capable of reducing both bandwidth and storage consumption by up to 80%* while maintaining the highest standard of image quality.

Specifications

System Information

• CPU - Multimedia SoC (System-on-Chip)
• Flash - 128MB
• RAM - 512MB

Camera Features

• Image Sensor - 1/3" Progressive CMOS
• Maximum Resolution - 1920x1080 (2MP)
• Lens Type - 20x Optical Zoom, Auto Focus
• Focal Length - f= 4.7 ~ 94 mm
• Aperture - F1.6 ~ F3.5
• Auto-iris - DC-iris
• Field of View
  • 3° ~ 55° (Horizontal)
  • 2° ~ 33° (Vertical)
  • 3° ~ 63° (Diagonal)
• Shutter Time - 1/8 sec. to 1/30,000 sec.
• WDR Technology - WDR Pro
• Day/Night - Removable IR-cut filter for day & night function
• Minimum Illumination - 0.26 Lux @ F1.6 (Color) 0.01 Lux @ F1.6 (B/W)
• Pan Speed - 0.05° ~ 450°/sec.
• Pan Range - 360° endless
• Tilt Speed - 0.05° ~ 450°/sec.
• Tilt Range - 110°
• Preset Locations - 256 preset locations, 128 presets per tour
• Pan/tilt/zoom Functionalities - 128x digital zoom (4x on IE plug-in, 32x built-in) Auto pan mode Auto patrol mode
• On-board Storage - Slot type: SD/SDHC/SDXC card slot Seamless Recording

Video

• Compression - H.265, H.264, MJPEG
• Maximum Frame Rate
  • H.265 & H.264 - 60 fps @ 1920x1080
  • MJPEG - 30 fps @ 1920x1080
• Maximum Streams - 4 simultaneous streams
• S/N Ratio - 53 dB
• Dynamic Range - 100 dB
• Video Streaming - Adjustable resolution, quality and constant bit rate control; Smart Stream II
• Image Settings - Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks (up to 24); Scheduled profile settings, EIS, 3DNR, defog

Audio

• Audio Capability - Two-way Audio (full duplex)
• Compression - G.711, G.726
• Interface - External microphone input External line output

Network

• Users - Live viewing for up to 10 clients
• Protocols - IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, NTCIP, ARP, SSL, TLS
• Interface - 10 Base-T/100 BaseTX/1000 BaseTX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
• ONVIF - Supported, specification available at www.onvif.org

Intelligent Video

• Video Motion Detection - Five-window video motion detection
• Auto-Tracking - Auto-tracking on moving object

Alarm and Event

• Alarm Triggers - Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, audio detection
• Alarm Events - Event notification using digital output, HTTP, SMTP, FTP, NAS server and SD Card File upload via HTTP, SMTP, FTP, NAS server and SD card

General

• Connectors
  • RJ-45 cable connector for Network/PoE connection
  • Audio input
  • Audio output
  • 24V DC / 24V AC power input
  • Digital input*4
  • Digital output*2
  • RS-485
• LED Indicator - System power and status indicator
• Power Input - 24V DC 24V AC 60W UPoE
• Power Consumption - Max. 48/26 W (Heater on/off)
• Dimensions - Ø 162 x 221 mm
• Weight - 2.95 kg
• Casing - Weather-proof IP68-rated, Vandal-proof IK10-rated, and NEMA 4X-rated mated housing
• Safety Certifications - CE, FCC Class A, VCCI, C-tick, UL, NEMA 4X
• Operating Temperature - -40°C ~ 65°C (-40°F ~ 149°F)
• Humidity - 90%
• Warranty - 36 months

System Requirements

• Operating System - Microsoft Windows 8/7/Vista/XP/2000
• Web Browser - Mozilla Firefox 7~43 (streaming only) Internet Explorer 7/8/9/10/11
• Other Players - VLC: 1.1.11 or above Quicktime: 7 or above

Included Accessories

• CD - User's manual, quick installation guide, Installation Wizard 2, VAST
• Others - Wall mount bracket, screws, waterproof connectors, quick installation guide, alignment sticker, L-wrench, software CD, desiccant bags, I/O combo cable

SD9361-EHL Specifications PDF
