[DISCONTINUED] RC-03-MCT-K ISONAS PowerNet IP Reader-Controller with Keypad - Mullion - 125kHz and 13.56MHz

Search available promotions and discounts for this Item

SKU: RC-03-MCT-K

Brand: ISONAS

Proven Innovation – Our patented PowerNet Reader-Controller provides the fi rst "pure IP" to-the-door solution that eliminates the need for a separate power supply, control panel and dedicated hard wiring.
Greater Value – Compared to traditional systems that require more equipment, labor and maintenance, the total cost of ownerships i far less.
Total Flexibility – The ability to easily integrate with other systems and go where other access control solutions can't gives you the freedom to adapt to changing needs.
Intelligence at the door – A single PowerNet is capable of storing 64,000 cardholders, 5000 access events and 32 time zones which can be confi gured and accessed by an external host system.
IP architecture allows management of thousands of Reader-Controllers on a single computer across a geographically disbursed network.
Use our DHCP functionality or call home capability to seamlessyl connect to the host computer to create a simpler installation.
The Open Systems platform enables seamless integration with other systems, including SQL, and TCP/IP. The powerful integration with Video Management Systems allows a fully comprehensive security solution.
Our local mode feature allows readers to function without the host. This results in faster user response times, less network traffic and reduced host system loading.

More details...

Search available promotions and discounts for this Item

MPN: RC-03-MCT-K

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

The industry's first panel-free IP reader controller to deliver true Power Over Ethernet, our PowerNet Reader provides the freedom to secure an unlimited number of doors without the hassle of having to wire panels or hubs. Reader Controller

Specifications

CONSTRUCTION

Mullion Form Factor
Flame Retardent ABS
Potted for greater weather resistance
Dimensions: 1.625" X 6.750" X .940" (mullion)

POWER OPTIONS (fi eld selectable)

Power Over Ethernet (PoE), (IEEE 802.3af, Class 0)
DC power: <125 mA @ 12 volts DC, < 70 mA @ 24 volts DC

NETWORK COMMUNICATIONS

Ethernet, TCP/IP, standard RJ45
Network Host or Client modes supported
ASYNCH communications – no polling
Field fl ashable microcode

ENVIRONMENTAL

UL-294 and rated for Outdoor use
Meets FCC Part 15 certifi cation, ambient operating
temperature -40 to 50^° C (-40 to 120^° F), operating humidity is 0 – 100%
Exposure Ratings: IP56 and NEMA Type 4X

OUTPUTS

12 wire pigtail detachable
2 TTL outputs
1 Lock control circuit (NC&NO Supported)
Power Output; 0.6amps at 12V

INPUTS

Three confi gurable inputs
- Door Sense
- Request to Exit (REX)
- Optional Input (AUX)
RS232 interface to connect serial devices like Pin Pads and Wiegand readers

VISUAL INDICATOR
