HCV-6070R Hanwha Vision 3.2-10mm Varifocal 30FPS @ 2MP Outdoor IR Day/Night WDR Dome HD-TVI/HD-CVI/AHD/Analog Security Camera 12VDC/24VAC

SKU: HCV-6070R

Brand: Hanwha Vision

2MP Analog HD IR Outdoor Dome

Features:

Full HD resolution
0.11Lux@F1.4(Color), 0Lux(B/W : IR LED on)
3.2~10mm(3.1x) V/F lens
Day & Night(ICR), WDR(120dB)
SSNR, Motion detection
IR viewable length : 98 feet, IP66, IK10, Dual power
Transmission distance maximum 500m
Easy installation (Plug & play), Dual power, RS-485

More details...

MPN: HCV-6070R
EAN: 8801089131133

MSRP Price: $300.00

Web Price$300.00

Quantity:

Add to List

DWG Dealer Program Become a DWG Dealer to see your pricing. Dealer pricing, quoting, volume discounts, and sales support on thousands of products.

Become a DWG Dealer → DWG Dealer Sign In

Product Details

Specifications

Video

Imaging Device - 1/2.8" CMOS
Resolution - 1920x1080
Max. Framerate(NTSC/PAL) - 30fps/25fps
Min. Illumination - Color(1/30sec, 30IRE) 0.11 BW: (1/30sec, 30IRE) 0.011
Video Out - BNC: AHD/TVI/CVI/CVBS Selectable
Video Transmission Distance - 500m(5C2V Coaxial Cable)

Lens

Focal Length (mm) - 3.2~10
Optical Zoom Ratio - 3.1x
Max Aperture Ratio (F number) - Wide 1.6
Angular Field of View Horizontal - 110.2°~32°
Angular Field of View Vertical - 55.4°~18°
Angular Field of View Diagonal - 128.4°~36.6°
Min. Object Distance - 0.5m(1.64ft)
Focal Control - Manual
Lens Type - DC auto iris(IR corrected)
Optional Lens - 0.5m(1.64ft)

Pan / Tilt / Rotate

Pan / Tilt / Rotate Range - 0˚~350˚ / 0˚~67˚ / 0˚~355˚

Operational

Day & Night - Auto(ICR)
Backlight Compensation - BLC, HLC, WDR
Wide Dynamic Range (dB) - 120
Digital Noise Reduction - SSNRⅣ
Defog - Support
Motion Detection - 4 ea
Privacy Masking - 8ea
Shape - Rectangular zones
Gain Control - Low / Middle / High / Very High
White Balance - ATW / AWC / Manual / Indoor /
Electronic Shutter Speed Range - 1~1/12,000sec
Video Rotation - Flip, Mirror
Alarm Interface In/Out - Output 1ea
Alarm Triggers - Analytics
Alarm Events When Alarm Trigger Occurred - Alarm output
IR Viewable Length - 30m(98.43ft)
Coaxial Protocol - ACP, TCP, CCP, CVBS

Analytics

Analytics Events - Normal Motion detection

Environmental & Electrical

Operating Temperature/Humidity - -30°C~+55°C(-22°F~+131°F)/ 0~90% RH(non-condensing)
Input Voltage - 24VAC,12VDC
Power Consumption - 12VDC Max 4.2W, 24VAC Max 4.2W

Mechanical

Color - Ivory
Material - Aluminum
Product Dimensions - Ø137x106.1mm(5.39x4.18")
Product Weight - 715g(1.58 lb)

Certifications & Standards

Environment - IEC 60529 IP66, IEC 62262 IK10

HCV-6070R Specifications PDF
